The IS200TRPAH1A is a Primary Trip Terminal Board used in GE Industrial Mark VI Turbine Control Systems.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a IS200TRPAH1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200TRPAH1A
  • SKU: GBTC-14891
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark VI IS200

IS200TRPAH1A Technical Specifications

Part Number IS200TRPAH1A
Product Type Primary Trip Terminal Board
Functional Acronym TRPA
Weight 12 ounces
Shipping Dimensions 18x13x13 inches

Frequently Asked Questions about IS200TRPAH1A

What is this IS200TRPAH1A device's A-rated functional revision's rarity?

This IS200TRPAH1A product's A-rated revision is about the most common across the entire GE Mark product series suite.

Does the IS200TRPAH1A circuit board feature any factory-drilled installation holes in its product makeup?

Yes. Several holes have been drilled in the IS200TRPAH1A device's base board for installation purposes specifically.

About the IS200TRPAH1A

Greater Series Alignment Information

The IS200TRPAH1A is a component (PCB) created by GE for the Mark VI system. One of the last of the Speedtronic series, the MKVI is a gas/steam turbine management system built with central control. The central control module, or modules in TMR (triple modular redundant) systems, are connected to termination boards that in turn bring I/O to/from the rest of the boards in the system.

The Central control module(s) connect to an operator interface loaded with software like CIMPLICITY graphics and the Control System Toolbox. This interface and software allow users access to software configuration tools and turbine data.


IS200TRPAH1A Device Specialized Hardware

The IS200TRPAH1A functions as a Primary Trip terminal board. This is part of the Turbine Specific Primary Trip I/O pack that is designated IS200PTURH (1A or 1B.) The IS200TRPAH1A has

  • Speed input rating of -15 to 140 Vdc
  • E-stop input rating of 18 to 140 Vdc
  • Voltage detection input rating of 16 to 140 Vdc
  • Contact out voltage of 24 Vdc nominal, 28 Vdc maximum

The IS200TRPAH1A has eight connectors, including six 37-pin cable connectors. These are located in two lines of three. There are two vertical pin connectors (P1/P2.)  There are also two terminal blocks. Each terminal blocks have twenty-four screw connections. The board has integrated circuits, resistors, TP test points, capacitors, transistors, and diodes. The board is marked with multiple codes, including the board id number, 6DA00, and 6BA00. The board has two factory-made holes designed for screw-connected mounting to a secondary surface.

More information on the IS200TRPAH1A can be found through manufacturer publications. AX Control suggests following all GE handling procedures. We handle all MKVI boards as static-sensitive. This board will be shipped protected by an anti-static wrap.
