The IS200EDFFH3AAA EX2100e DC Fanned Feedback Board

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a IS200EDFFH3AAA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200EDFFH3AAA
  • SKU: GBTC-53403
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark VI IS200

IS200EDFFH3AAA Technical Specifications

Functional Part Number IS200EDFFH3AAA
Instruction Manual Number GEA-S1301A
Functional Description EX2100e DC Fanned Feedback Board
Abbreviation EDFF
Made In USA
Revision Quantity 3 Revisions
Backwards-Compatibility 1st two revisions

About the IS200EDFFH3AAA

The IS200EDFFH3AAA  is a small rectangular board that functions as a DC-fanned feedback board. This board works together with the EAUX control interface card, connected together via high-speed fiber-optic connections. The EDFF board is used for the measurement of field currents, and can also be used for the measurement of field voltage in the SCR bridge. Secondarily, the board can be used to scale or convert field current and voltage at the regulator output to turn it into a usable frequency feedback signal. The IS200EDFFH3AAA can only be used with and is only compatible with simplex systems. This board will not work with triple modular redundant setups. Please refer to a similarly named H1 board if you are running a TMR system.  Similarly named H2 boards are required for dual systems. The IS200EDFFH3AAA is:

  • drilled in each corner for mounting
  • in possession of fiber optic connectors
  • also utilizing vertical connectors and standoffs
  • marked with the GE logo, with the IS200EDFFH3AAA part number, and several codes

IS200EDFFH3AAA Catalog Number Described

This IS200EDFFH3AAA Feedback Board's IS200EDFFH3AAA functional product number begins with an iteration of the dual-functioning IS200 series tag delegating this IS200EDFFH3AAA product's normal Mark VI Series assembly on top of its domestic original manufacture location. Some of the other relevant IS200EDFFH3AAA Board details are the IS200EDFFH3AAA PCB's:

  •  EDFF functional product abbreviation
  • unique conformal style of PCB protection
  • group three Mark VI Series product grouping
  • full, three-fold product revision history

Frequently Asked Questions about IS200EDFFH3AAA

Where specifically was this IS200EDFFH3AAA device manufactured?

This IS200EDFFH3AAA PCB is a domestically-based GE product, with an orgin specifically in their Salem, Virginia factory plant location.

Have each of this IS200EDFFH3AAA product's factory-drilled installation holes been ringed with an insulated material?

Yes. Each one of this IS200EDFFH3AAA product's drill-holes have been ringed with insulated material in observance of potentially-present IS200EDFFH3AAA Board surface voltages.

Reviews For IS200EDFFH3AAA

Internal Review
(5.0)

The IS200EDFFH3AAA EX2100e DC Fanned Feedback Board lacks a significant installed base and is therefore quite limited in terms of market availability. The upside is that the IS200EDFFH3AAA contains very few high failure rate components and is one of the more reliable components in an Excitation Control System. The simplicity of the boards construction also allows for economical repair when needed. This IS200EDFFH3AAA device has two functional revisions and an artwork configuration revision, and is available for repairs here as well. - AX Control Lead Technician

Repair Services For IS200EDFFH3AAA

Type Lead Time Price Action
Repair Service 1-2 weeks $1120

Our highly skilled technicians can repair your IS200EDFFH3AAA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
