General Electric's IS200ISBBG1AAA model is an Insync Bus Bypass Card. It operates in the Mark VI series. This unit features a JP1 Interlock Bypass. The settings on the interlock bypass can be set to bypassed or unbypassed.

Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS200ISBBG1AAA to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS200ISBBG1AAA
SKU: IS200ISBBG1AAAGBTC

Manufacturer: GE Boards & Turbine Control
Series: Mark VI IS200

Description
Repairs
Warranty
Manuals

IS200ISBBG1AAA Technical Specifications

Part Number	IS200ISBBG1AAA
Series	Mark VI
Manufacturer	GE, General Electric Boards and Turbine Control
Functional Acronym/Abbreviation	ISBB
Model Type	InSync Bus Bypass Card
Weight	Less than 1 pound

Frequently Asked Questions about IS200ISBBG1AAA

What is the IS200ISBBG1AAA model?

The IS200ISBBG1AAA model is an Insync Bus Bypass Card. This model works with the Mark VI IS200 series. Unfortunately, it is unsure what the model's primary function is due to a lack of documentation. For more information, it would be wise to contact General Electric to either receive documentation or information on the board.

What do the jumpers on the IS200ISBBG1AAA model do?

The jumpers on the IS200ISBBG1AAA model have two settings. One is bypassed, and the other is unbypassed. The bypassed jumper is 2-3, and the unbypassed jumper is 1-2. For more information on the difference between the two jumpers, refer to any of the available documentation that you can find. General Electric would be the best source of knowledge to find out what the difference between the two jumpers is.

Product Description

The IS200ISBBG1AAA functions as an Insync Bus Bypass card. It is a small circuit board with several factory-made drill holes located in each corner. Four of these are encircled with a conductive material; these are labeled E1 through E4. In some cases, these holes are used to mount the card to DIN rails. The board also carries its board number and the codes 6BA01 and 6DA01.

The IS200ISBBG1AAA is populated by two relays with printed relay diagrams. The board has a yellow LED indicator labeled XMIT Data and a green LED indicator labeled Interlock Active. It has two rectifier diodes, a single integrated circuit, one jumper switch, several ceramic capacitors, metal film resistors, and diodes. The board’s jumper can be set to 1-2 (unbypassed) or 2-3 (bypassed.)

Other board components on the IS200ISBBG1AAA include one (1) two-position terminal strip, labeled 24 VDC Input and three female plugs. These are labeled RCV Data In, XMIT Data Out, and Full Duplex. Refer to publications from GE (manuals, data sheets, user guides) for more information on this product.

While the IS200ISBBG1AAA model can be found readily available the actual documentation of the ISBB model is very limited. All of the documentation for the ISBB model would have to be acquired from General Electric.
