Product Description
The IS200FOSAG1A model is a circuit board created and manufactured by General Electric. The IS200FOSAG1A model is classified as a printed circuit board to be installed into the GE Mark VI SPEEDTRONIC product family, which is a series of turbine control devices designed to fully integrate turbine control systems functions into one cohesive system. These system functions include protection, monitoring, and control systems that are found in generator and mechanical drive applications of both gas and steam turbines.
On the face of the IS200FOSAG1A printed circuit board lies ten brownish-red resistors, five at the top of the circuit board and five at the bottom. Resistors are used for a variety of functions, including reducing current flow, dividing voltage, adjusting signal levels, terminating transmitter lines, and dissipating watts of electrical power as heat. To the left of the top row of these brownish-red resistors lies a heatsink array. At the bottom left of the IS200FOSAG1A printed circuit board is a small grouping of many small electrical parts. There are two blue capacitors to the top right of the grouping and two yellow capacitors in the middle. To the bottom right of this grouping lie two integrated circuits. Below that, there are four ring test points, which are used to monitor the circuitry on the circuit board. Directly to the left of these four test points lies a small LED indicator light.
Without including any of AX Control’s safe and reliable packaging to the total, the IS200FOSAG1A printed circuit board has an approximate weight of 1.00 lbs. or 0.454 kg.
