The GE Mark VI IS200DSPXH1ADA is a printed circuit board created by GE for the Mark VI series. This board is part of GE's speedtronic series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a IS200DSPXH1ADA to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

IS200DSPXH1ADA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
The GE Mark VI IS200DSPXH1ADA is a printed circuit board created by GE for the Mark VI series. This board is part of GE's speedtronic series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a IS200DSPXH1ADA to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Product Description

The IS200DSPXH1ADA circuit board, which is part of the GE Mark VI Speedtronic line, is a Digital Signal Processor Control board.  This PCB is designed for use within  Innovation Series drives and within EX2100 exciters to provide processing, interface, and logic functions.

The  IS200DSPXH1ADA is built with a high-performance DSP (digital signal processor)  and an application-specific integrated circuit. The board runs at 60MHz.    The board includes a watchdog timer, stack overflow detection, and also has five differential pair application inputs that drive two 16-bit up/down counters.   These can also be used as up to ten discrete inputs.

The IS200DSPXH1ACA has a front faceplate with two embedded LED indicators.  These are labeled “Status” and “Fault.”  The Status LED is green.  It is driven by the DSP and will flash when the DSP is running.   Solid on means stopped, and off means a fault has occurred.   The Fault LED is red.  It is also run by the DSP.  The Fault LED remains off when no faults are present but will be on or flashing during reset or if a fault is detected.

The IS200DSPXH1ACA has multiple port I/O connectors.  This includes a P1 backplane connector, a P5 DSP emulator port, and a P6 engineering monitor port.  The P5 and P6 ports are mounted into the front faceplate.   There is also a P7 vertical pin port that is typically only used during development.

For additional information about the IS200DSPXH1ACA, please refer to datasheets, user guides,  or manuals provided with your original equipment from the manufacturer.  If these have been misplaced or lost, AX Control may be able to provide you with replacement copies along with your order.


Reviews For IS200DSPXH1ADA
Internal Review

This board functions as a primary controller for the bridge and motor regulator and offers gating functions for GE Innovation Series drives. It is used to control generator field control functions. The board runs at 60 MHz. There are multiple variations of the DSPX board available, so please be sure to order the correct one for your application. Read more about this in associated manuals or reach out to our team--AX Control Tech Team.

Repair Services For IS200DSPXH1ADA

Type Lead Time Price Action
Repair Service 1-2 weeks $610

Our highly skilled technicians can repair your IS200DSPXH1ADA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
