The IS220PDOAH1A Discrete Output Pack

Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS220PDOAH1A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS220PDOAH1A
SKU: GBTC-54222

Manufacturer: GE Boards & Turbine Control
Series: Mark VI IS200

Description
Repairs
Warranty
Manuals

IS220PDOAH1A Technical Specifications

Compatible With	Six Discrete Output Terminal Boards, including SRLY and TRLY
Connectors	3; 1 DC Connector and 2 RJ45 Connectors
Dimensions	3.25" high x 1.65" wide x 4.78" deep
LED Quantity	Four; Power, Attention, TxRx, and Link
Memory Types	Flash and RAM
Mounting Strategy	Surface-Mount
Number of Ethernet Ports	Two
Power Management	28 V Input
Relay Channels Quantity	12
Exterior Chassis Type	Vented Chassis

About the IS220PDOAH1A

Characterized as a Discrete Output Pack the IS220PDOAH1A model was designed with interfacing up to two I/O Ethernet networks and other discrete output terminal boards in mind. One special function of this model is that it can control up to twelve relays as well as accept feedback signals from other terminal boards. The typical relays that can be used with this model are solid-state relays and electromagnetic relays. The solid-state relays are used with the TRLYH1B, C, D, and F terminals whereas the electromagnetic relays are used with the TRLYH1E boards. There are also:

multiple processors
- status-indicating LEDs
- local power supplies for monitoring and sequencing
- a high-speed processor with flash and RAM memory
double RJ45 Ethernet connectors
a three-pin power input
a processor board embedded in the IS220PDOAH1A pack
an output enable feature that is used with the IS220PDOAH1A pack

During the application in which power is given to the pack, all of the outputs will be disabled until a number of internal self-tests have been fulfilled. The enable function can provide paths that are independent of the command which will ensure that the relays are staying dropped out during the initialization and power-up of the pack.

IS220PDOAH1A Discrete Output Pack Standard Hardware

This IS220PDOAH1A Discrete Output Pack device's special modular I/O Mark VI Series assembly version and domestic original GE manufacture were determined upon analysis of its initial dual-functional IS220 series tag. Some of the other relevant information dictated through this medium include the IS220PDOAH1A Discrete Output Pack's:

PDOA functional product acronym
Group one Mark VI Series grouping
Conformal PCB coating style
A-rated revision

Frequently Asked Questions about IS220PDOAH1A

Where specifically was the IS220PDOAH1A Discrete Output Pack device manufactured?

This IS220PDOAH1A Discrete Output Pack PCB was first made in General Electric's Salem, Virginia factory plant location.

Is this IS220PDOAH1A Discrete Output Pack device's A-rated revision a common style of Mark Series revision?

Yes. This IS220PDOAH1A Discrete Output Pack product offering's sole A-rated functional product revision is the most common revision across the entirety of General Electric's Mark Series Suite.

Reviews For IS220PDOAH1A

Internal Review

(4.0)

When using this model any/all of the visual diagnostics needed to determine the function of the PDOA pack will be located on the front of the device. If for any reason one of the LEDs does not work it will likely need to be replaced to ensure that everything is working properly. This IS220PDOAH1A Discrete Output Pack device's conformal PCB coating style is much thinner yet further-reaching in terms of its overall protection when compared with the normal style of PCB coating. This IS220PDOAH1A Discrete Output Pack is also available for expedited or normal replacement or repair. - AX Control Lead Technician
