The IS200VAICH1CAB VME Analog Input Board was manufactured by General Electric as a member of the Mark VI Series of turbine control systems.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a IS200VAICH1CAB to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200VAICH1CAB
  • SKU: IS200VAICH1CABGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark VI IS200

IS200VAICH1CAB Technical Specifications

Manufacturer GE General Electric
Series Mark VI
Part Number IS200VAICH1CAB
Functional Description Analog I/O Board
Instruction Manual GEH-6421
Functional Acronym VAIC
PCB Coating Conformal Coating
Functional Revision 1 C
Functional Revision 2 A
Artwork Revision B

Frequently Asked Questions about IS200VAICH1CAB

Which applications does IS200VAICH1CAB support?
IS200VAICH1CAB supports both simplex and TMR applications. For further description of configuration of IS200VAICH1CAB in each application, view the manual for IS200VAICH1CAB - Manual GEH-6421.
Which terminal boards will IS200VAICH1CAB work with?
IS200VAICH1CAB will work properly with all revisions of DTAI terminal boards because IS200VAICH1CAB is a VAICH1C version. Versions following IS200VAICH1CAB will not work with all DTAI boards.
What is the output capacity for IS200VAICH1CAB?
When using two TBAI terminal boards, IS200VAICH1CAB has an output capacity of 0-20 mA or IS200VAICH1CAB has an output capacity of 0-200 mA.
Where can I find the manual for IS200VAICH1CAB?
We can provide you with the manual for IS200VAICH1CAB. The manual that applies to IS200VAICH1CAB is Manual GEH-6421. This manual is the Mark VI Turbine Control System Guide Manual and the manual covers IS200VAICH1CAB specifically. For a copy of IS200VAICH1CAB's manual, send a manual request for Manual GEH-6421.

Product Description

The IS200VAICH1CAB part number represents a General Electric board component for the Mark VI system.  The Mark VI is one of the more advanced versions of General Electric’s Speedtronic turbine control system.  Systems within the Speedtronic family have been used for industrial turbine control since the late 1960s.

The IS200VAICH1CAB functions as a VME Analog input board.  This is only one of several versions of the VAIC VME analog input board available within AX Control’s inventory; please be sure you purchase the exact equivalent to the board you have been working with to ensure complete compatibility with your system.

The IS200VAICH1CAB is a single-width I/O board that uses a common processor for Mark VI components, the TMS320C32.   The board includes RTD and thermocouple linearizations that allow high and low bad sensor data to be detected and alarmed.  The board is designed to accept tune-up commands and data from the GE toolbox while in an active state.

The IS200VAICH1CAB board offers 20 Analog inputs 0-1mA and four Analog inputs 4-20  mA.   It also has analog outputs that are rated 4-20 mA and 0-200 mA.  The board is built with two backplane connectors, a front faceplate, two retaining clips, and multiple components mounted to its surface including capacitors, ICs, resistors, and diodes.   Most components are marked with reference designations and with other identifiers.

General Electric manuals, product user guides, and specific data sheets will provide you with more details regarding handling, installation, and maintenance.  Please refer to these documents before unboxing your purchase from AX Control.
