The IS200HFPAG1A AC Fan/Power Supply Board

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS200HFPAG1A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS200HFPAG1A
SKU: GBTC-14595

Manufacturer: GE Boards & Turbine Control
Series: Mark VI IS200

Description
Repairs
Warranty
Manuals

IS200HFPAG1A Technical Specifications

Manufacturer	GE Industrial Systems
Series	Mark VI Speedtronic
Part Number	IS200HFPAG1A
Functional Acronym	HFPA
Functional Description	High Frequency Power Supply
PCB Coating	Normal Coating
Functional Revision 1	A

About the IS200HFPAG1A

The IS200HFPAG1A is a PCB component designed by GE for the Mark VI gas and steam turbine control system. The Mark VI is part of the Speedtronic line that has been under development by General Electric since the release of the first Mark I system in the late 1960s. Each Speedtronic system is designed to improve the reliability of GE’s heavy duty turbines. The Mark VI is built with a PC operator interface running on a Windows platform. The IS200HFPAG1A functions as an AC/Fan Power Supply for High-Frequency applications. The board receives input voltages (AC or DC) and converts the input into the needed output. This may be a 48 VAC, a 52 VAC, a 48 VDC, or a 17.7 VAC output. The output for the board (total) should not exceed 90VA. The IS200HFPAG1A is a multi-purpose board that may be mounted in various drive cabinets. It is usually mounted near a board rack or a fan enclosure. The IS200HFPAG1A is built with:

four stab-on input connectors
eight output plug connectors
a metal oxide varistor
four fuses
two LEDs (light emitting diodes)
two heat sinks
two transformers
three high-voltage capacitors
several transistors
capacitors of polyester vinyl and ceramic

Frequently Asked Questions about IS200HFPAG1A

Is the IS200HFPAG1A's base circuit board protected?

Yes. Beyond basic voltage-limiting circuitry mentioned before, this IS200HFPAG1A should be protected under a standard "Normal" PCB coat.

Is this IS200HFPAG1A repairable online here?

Yes. Give us a call at the number provided to inquire into an AX in-house repair of this IS200HFPAG1A "High-Frequency" model.

Reviews For IS200HFPAG1A

Internal Review

(5.0)

This Mark VI turbine control board is used as a high-frequency ac/fan power supply board. The board includes four stab-on connectors. These are used for voltage input. The board also has eight plug connectors used for voltage outputs. Refer to associated manuals to read about the four fuses on the board and how they provide for circuit protection. - AX Control Lead Technician

Repair Services For IS200HFPAG1A

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$465

Our highly skilled technicians can repair your IS200HFPAG1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
