IS200BICLH1AFE

Q: What does this IS200BICLH1AFE printed circuit board device&#39;s conformal PCB coating style include?

This IS200BICLH1AFE PCB&#39;s conformal style of PCB coating is a thin layer of chemically-applied protection extended to the entire base circuit board of this IS200BICLH1AFE product.

Q: Are this IS200BICLH1AFE product&#39;s three significant Mark VI Series product revisions considered backwards-compatible?

No. Only this IS200BICLH1AFE device&#39;s first two functional product revisions can be considered backwards-compatible.

4.85 (13)
Click a star to rate this product

4.85 (13)
Click a star to rate this product

The IS200BICLH1AFE Bridge Interface Controller Boar

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS200BICLH1AFE to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS200BICLH1AFE
SKU: GBTC-53551

Manufacturer: GE Boards & Turbine Control
Series: Mark VI IS200

Description
Repairs
Warranty
Manuals

IS200BICLH1AFE Technical Specifications

Original Manufacturer	General Electric
Original Product Series	Mark VI Speedtronic
Functional Part Number	IS200BICLH1AFE
Functional Abbreviation	BICL
Revision Quantity	3 Revisions
Backwards-Compatibility	1st two revisions
Assembly Type	Normal Assembly

About the IS200BICLH1AFE

The IS200BICLH1AFE is a Bridge Interface Controller Board. It is part of the GE Industrial Systems’ Mark VI Speedtronic line. The Mark VI was designed to offer triple modular redundant control to industrial gas and steam turbines. The IS200BICLH1AFE is used to:

interconnect the Innovation Series main control board and a BPIA bridge personality interface board
ensure ambient temperature monitoring control
maintain the speed control interface
control the fan

The control logic on the IS200BICLH1AFE comes from the CPU of the main control board. The IS200BICLH1AFE plugs into a VME rack using its P1 and P2 connectors..The front panel of the board is blank, barring two clips that help lock the board into place and a notation stating the user should “install in slot 5 only.”

Standard IS200BICLH1AFE Hardware

The board surface is marked with the board identification number, a barcode, and several other codes. Most components are marked for easy identification. The IS200BICLH1AFE will be shipped in a protective anti-static bag to keep it from any incidental damage during shipping. Most orders placed before 3 pm will be shipped out to you on the same day. If expedited shipping is desired, please let us know. We ship around the world. For more information about installation or handling procedures regarding the IS200BICLH1AFE, please refer to manuals or data sheets originally provided by the OEM. This is not the originally-developed product of its specific Mark VI Series functionality, given the revision history cited above. The IS200BICLH1AFE is designed with:

the aforementioned backplane connectors (P1 and P2)
four relays
over 18 resistors
30 capacitors
a dozen integrated circuits
several transistors

Frequently Asked Questions about IS200BICLH1AFE

What does this IS200BICLH1AFE printed circuit board device's conformal PCB coating style include?

This IS200BICLH1AFE PCB's conformal style of PCB coating is a thin layer of chemically-applied protection extended to the entire base circuit board of this IS200BICLH1AFE product.

Are this IS200BICLH1AFE product's three significant Mark VI Series product revisions considered backwards-compatible?

No. Only this IS200BICLH1AFE device's first two functional product revisions can be considered backwards-compatible.

Reviews For IS200BICLH1AFE

Internal Review

(5.0)

Be aware that the pin signal descriptions for this board will differ in some cases when this board is used with a BPIA or BPIB board vs when it is used with an SCNV board. Make sure to read through and understand pin signal tables in associated General Electric manuals for your particular functional application. With this being important, this IS200BICLH1AFE product is well-supported generally, with its special conformal style of PCB coating and its exercising of a full three-fold Mark VI Series revision history. Available here for both repair and replacement today. - AX Control Lead Technician

Repair Services For IS200BICLH1AFE

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$699

Our highly skilled technicians can repair your IS200BICLH1AFE. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
