Reliance Electric Shark XL 45C922 115/230 VAC Power Supply Module

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C922 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C922

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
Reliance Electric Shark XL 45C922 115/230 VAC Power Supply Module

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C922 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C922 Technical Specifications

Input Voltage 115/230 VAC
Manufacturer Reliance Electric
Part Number 45C922
Series Shark XL

Product Description

The 45C922 device is a power supply module that was created by Reliance Electric for the Shark XL series. Although the 45C922 power supply module is no longer in production, we may still have it in stock. For your convenience, we list the current availability of all of our products on our website, including the availability of the 45C922 power supply module.

The 45C922 power supply module is only one of three different kinds of power supply modules that were made to be inserted inside of Shark XL racks. The other two power supply modules use the model numbers 45C920 and 45C921. If you click on one of these links, you will be taken to the product’s page. From there, you can learn more about it and its availability at AX Control.

The 45C922 power supply module’s input voltage is jumper selectable at either 115 VAC or 230 VAC, the input current is 600 mA or below, and the input frequency is 47 through 63 Hz.

The power consumption of the modules in the rack must not go higher than the maximum load current of the 45C922 power supply module. Before you install the 45C922 power supply module, it is a good idea to check the power requirements of all of the I/O modules that you place into your rack to make sure that the total current does not go higher than the maximum load current of the 45C922 power supply module’s three channels. The first channel has a maximum load current of 5 VDC at 1700 mA, the second channel has a maximum load current of 24 VDC at 500 mA, and the third channel has a maximum load current of 24 VDC at 250 mA.

Frequently Asked Questions about 45C922

What is the function of the 45C922?
The 45C922 is a power supply module that connects to a rack. The 45C922 is one of three Reliance Electric Shark XL power supply modules.
Does the 45C922 have any output terminals?
Yes. The Reliance 45C922 has a 24 VDC terminal for powering output circuitry to the 45C922.
Does each Shark XL rack require a power supply module?
Each Shark Xl rack requires a power supply modules. The racks all have a slot designed specifically for the power supply modules.
Does AX Control offer a warranty with the 45C922?
AX Control offers a three year warranty with the 45C922. If your 45C922 stops working within the three years we will send you a new device, complete any repairs, or grant you a full refund.
