803620-TA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
This 803620-TA AC/DC Contactor was manufactured by Reliance Electric.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 803620-TA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 803620-TA
  • SKU: 803620TARE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

803620-TA Technical Specifications

OEM Reliance Electric
Product Number 803620-TA
Functional Description AC/DC Contactor
Device Status Now-Obsolete Legacy

About the 803620-TA

The 803620-TA is an interface assembly from Reliance Electric.  This may also be labeled as a Reliance Electric Contactor.   Reliance Electric has a long history of manufacturing electrical motors, drives, and associated components.  The company has been in business under some name since the first decade of the 20th century.  Some Reliance components may be sold under other company names due to mergers or acquisitions.  These company names include Baldor-Reliance and Asea Brown Boveri.

The 803620-TA functions as a Contactor within a larger system.  The contactor is composed of a housing base, a contact system, an electromagnetic system, and an arc extinguishing system.   The base is made up of a flat metal plate that has been factory drilled in several locations.  It includes several contact points to allow for connections from external sources along one edge.  These are individually numbered.  Contacts are wired to a vertically placed arc-extinguishing system.  This is also wired directly to a vertical component of the housing base.

Additional information about the 803620-TA contactor can be found through original documentation provided originally by Reliance Electric.  Reliance manuals, associated product guides, and detailed data sheets will give you a deeper understanding of how this product works and how it should be handled, maintained, and installed.   We strongly recommend reading through this information before unboxing your part from our facility.

AX Control supports manufacturers around the world with high-quality industrial automation replacement parts.  Let us know what we can do to help you maintain your desired uptime and machine reliability.


  • O-3620-TA

Repair Services For 803620-TA

Type Lead Time Price Action
Repair Service 1-2 weeks $295

Our highly skilled technicians can repair your 803620-TA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
