Reliance Obsolete Board

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 107075-023R to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 107075-023R
  • SKU: 107075023RRE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

Product Description

The 107075-023R  board component from Reliance Electric is designed as a replacement part for the company’s drive control systems.  Your original components may have been delivered under the company names of ABB, Asea Brown Boveri, Reliance, or Baldor Reliance, but typically they are compatible across company name changes.

The 107075-023R  is designed with a double-wide front-attached faceplate that connects to the simple circuit board portion of the unit.  The circuit board has a flat backplane connector that extends from its rear edge to allow the unit to communicate with other board components within the same system.  The faceplate is designed with two set screws to lock the unit into place once it has been installed, and includes multiple rotary dials.  Each dial is marked from zero to ten with hash marks located between each number for finer tuning.  Each dial has been individually labeled with its use on the front of the faceplate.  Additionally, each dial connects to a potentiometer that is mounted to the front board edge of the circuit board.

Other board components include vertical pin connections, surface wiring, resistors, and capacitors.   More information is readily available regarding this board, its use, and associated proper installation and maintenance procedures in documentation like manuals and user guides from the OEM.

AX Control maintains a large warehouse full of industrial automation replacement parts to better fulfill your orders in a timely manner.  Let us know what we can do for you today.  Our staff will expertly package your order and have it on its way within hours of your purchase order’s arrival.


  • O-7075-023R

Repair Services For 107075-023R

Type Lead Time Price Action
Repair Service 1-2 weeks $352

Our highly skilled technicians can repair your 107075-023R. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
