0-58704

Product Description

The 0-58704 is an interface drive board created by Reliance Electric. There are eight transformers on this circuit board. Each transformer is labeled 3051-001 9426 across their tops. There are five large matt black resistors to the right of the transformers. Each resistor has its limits written along the outside. There are five integrated circuits to the right of the resistors. The interface drive board also has two large black boxes labeled Omron made in Japan, LZNQ4 – UA – 006068, 24 VDC contact resistive 0.3A 125 VAC, 1A 30 VDC Coil 24 VDC. These boxes also have the Reliance Electric logo and a circuit diagram as well. There are eight signal diodes (black with a silver line). The 0-58704 also uses eight light pink resistors with banding, twenty-one yellow resistors, and four silver resistors. The circuit board has over forty short metal jumper pins. These jumper pins are broken up into sections with varying numbers of pins in each section and then labeled. The labels are D2E, D2A, D2B, D2C, D2D, E1, and E2. Then there are seven larger metal pins that are labeled F4. The 0-58704 drive board uses the alphabet and double letters AA -AW to label the width of the circuit board and numbers to measure out the length. The numbers for the length go from zero to eighty and are broken up into sections of five with tick marks that represent each number in between the two printed numbers.

Let AX Control provide you with a quote.
