This 0-56300 PC Mother Board was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 0-56300 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-56300
  • SKU: 056300RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-56300

Reliance Electric is the maker of the 0-56300. The 0-56300 has two very large transformers that are not secured to the circuit board but are kept off to the sides and connected by wires. This board has five large blue capacitors that are secured to the circuit board by zip ties. On the right-hand side of the 0-56300 are a long light blue female style connector and two large white rectangular boxes that are also connection ports. 0-56300 has two long white connection across the back section of the circuit board. ON this board there is a green metal post in the back-left corner. The 0-56300 uses various numbers of smaller capacitors, resistors, transistors, and diodes across the surface of the circuit board. The front of the 0-56300 has a small black box with three opening, on top of each opening is a small screw. To the right of the three-screw black box is a long box with about eleven openings and like the smaller box, each opening has a corresponding screw on top. Another feature of the 0-56300 is a large power relay on the left side. The power relay is the large clear plastic box on the surface of the circuit board. There is also a smaller power relay to the left of the large power relay.

AX Control’s knowledgeable staff is waiting to hear from you and offer their services to help get the products you need in one place to get back up and running. Call or email AX Control today.

  • O-56300

Repair Services For 0-56300

Type Lead Time Price Action
Repair Service 1-2 weeks $415

Our highly skilled technicians can repair your 0-56300. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
