Circuit Card PC Board

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 0-55325 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-55325
  • SKU: 055325RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

Product Description

The 0-55325 is a small circuit board from Reliance Electric.  This board was sometimes sold as an Asea Brown Boveri part but was designed the same way regardless of the name on the packaging.  It is typically used within a Reliance Brake Resistor.  It is no longer available from the original equipment manufacturer but typically can be found here at AX Control as part of our in-stock merchandise as a remanufactured part.  Sometimes this board may be available as new, never used surplus.  Please check with our sales department for current availability and pricing.

The 0-55325 is a very small board that weighs 0.03 pounds before the addition of external boxing or packaging material.  Because this is a static-sensitive board, we typically wrap it in anti-static material before shipment to protect it during transit.  We recommend the use of a grounding strap while unboxing and installation.

Because of its size, the 0-55325 only has a few components located on its surface.  This includes several stab-on connectors, a diode on the left side of the board, and a few capacitors.  The unit also has several wires leading from its surface leading to different connectors.  These wires are red, black, or white.

The 0-55325 board is marked with the Reliance logo and with the board’s ID number.

More information regarding the proper use and installation of this product can be found through Reliance documentation like data sheets, user guides, and manuals.  If you need this part quickly, AX Control offers expedited shipping options.  Please let us know when you place your order so we can help you choose the fastest shipping option for your location.

  • O-55325

Repair Services For 0-55325

Type Lead Time Price Action
Repair Service 1-2 weeks $301

Our highly skilled technicians can repair your 0-55325. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
