PC Driver Board Card

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 0-54394-3 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-54394-3
  • SKU: 0543943RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

Product Description

The 0-54394-3 is a small base driver card by Reliance Electric. This circuit board is propped up on a metal base by four plastic pegs. The circuit board has a zero to fifty labeled edge with increases of five. The other edge is A through Z AA through AY and BA. Even though this circuit board is compact it holds quite a lot of components. The circuit board has two large mat black resistors, about twenty various other resistors with either their abilities printed on them or solid light blue with bands, or dark brown with bands. All of them in a variety of sizes. The bands can be read using a chart to determine that resistors abilities. The circuit board has an array of diodes as well ranging in color from black with a silver line, to orange and glass-like with a black line, to white with a black line. Each diode regardless of color or size also has its abilities marked on the side. There is integrated circuits that store data for the circuit board. The circuit board also has capacitors ranging from large to small and of different shapes and colors. There are orange squares, mustard brown circles which fall under the polyester style of capacitors, and larger dark-colored PCB Mount Electrolytic capacitors. There is also a crystal oscillator with a black metal fence around it. The circuit board also has four large black wires across the surface as well as a white and a red wire that is twisted together that runs across the surface.

  • O-54394-3

Repair Services For 0-54394-3

Type Lead Time Price Action
Repair Service 1-2 weeks $385

Our highly skilled technicians can repair your 0-54394-3. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
