This 0-54349-2 Phase Control Board was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-54349-2 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-54349-2
  • SKU: 0543492RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-54349-2

The 0-54349-2 is a phase sequencer circuit board made by Reliance Electric. This circuit board has four large red “MEMCOR” resistors, two small red resistors, four light brown resistors, two pale teal resistors, one large dark brown resistor with bands, and seven small dark brown resistors with bands. The circuit board has eight small black diodes with a gray band, there is a circle on the surface of the circuit board where the diode connects to the circuit board on the side of the diode that has the gray strip. The circuit board also has five white didoes with a dark gray stripe. Where these didoes connect to the circuit board there is also a circle on the surface of the circuit board on the side of the diode that has the dark gray stripe. There is a large yellow capacitor, a large silver capacitor, and a smaller silver capacitor. Each capacitor has writing on the outside that explains the amount of energy they can withstand. There is a tiny circular transistor toward the bottom of the circuit board. Directly above the transistor are three pins in a white outlined box, each pin is labeled TP2, TP3, and TP4. There are three more pins toward the bottom right of the circuit board in a white box they are labeled with numbers but are difficult to see because they are covered with resistors. Along the top edge of the circuit board, there are five flat metal tabs that are used to attach wires to the circuit board.

Frequently Asked Questions about 0-54349-2

Can AX Control repair my 0-54349-2?

Yes. This 0-54349-2 product offering is available for both repair and replacement here at AX Control, with a standard one to two week lead repair time.

Have any factory-drilled holes been made in the base circuit board of this 0-54349-2 product?

Yes. The base circuit board of this 0-54349-2 device has been factory-drilled in several locations to support convenient and safe installation practices.
