This 0-54339-1 Control Board was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-54339-1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-54339-1
  • SKU: 0543391RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-54339-1

The 0-54339-1 is a very large printed circuit board created by Reliance Electric. Despite this circuit boards size, it is rather barren to begin with, however it can be customized to fit your needs. The circuit board comes with to the far-left side of the circuit board is a black diode with a gray line, three black wire sections, seven orange and gray glass diodes, an orange rectangular condenser, a dark brown stripped resistor, a microchip, and five small sections of wire either black or gray in color. The circuit board on the top left corner a blue plastic ribbon harness connector with side clips to secure the connector. Below the ribbon harness connector is a series of eight brownish orange circular style condensers. To the right of the circular condensers are eight black half circle transistors. These sixteen pieces are enclosed by six blue rectangular components. Below this section are two more microchips two more sections of black wire. Moving towards the right side of the circuit board are four more microchips and three more sections of wire, along with an orange circular capacitor and a red rectangular capacitor. The top of the circuit board has two black connectors with forty gold pins in each connector. There is also one last larger microchip, another red rectangular capacitor and five more black sections of wire. The circuit board does utilize a grid pattern with number labels on one edge and letter labels on the other edge.

AX Control’s staff is here to answer any questions you may have.

Frequently Asked Questions about 0-54339-1

Would this 0-54339-1 device be protected by any warranty upon my purchase here?

Yes. Immediately upon your original purchase from AX Control, this 0-54339-1 product and many others would be considered protected by our guaranteed three-year warranty.

How is voltage protection handled in the assembly of this 0-54339-1 product offering?

This 0-54339-1 device's voltage limitation is produced through its internal assembly's inclusion of Reliance Electric-standardized hardware components such as capacitors, diodes, and resistors.
  • O-54339-1

Repair Services For 0-54339-1

Type Lead Time Price Action
Repair Service 1-2 weeks $299

Our highly skilled technicians can repair your 0-54339-1. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
