This 0-54201-2 Dual Processor Automate Board was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-54201-2 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-54201-2
  • SKU: 0542012RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-54201-2

The 0-54201-2 is a Dual Processor Automate Board created by Reliance Electric. This circuit board is rather large. The upper edge is marked out in increments of five from the number zero to one hundred and twenty-five. The side edge is labeled with the alphabet from A to Z then using double letters AA (going through the whole alphabet in the second letters spot), then goes to BA (and going all the way to M in the second letter spot). This circuit board has one small red LED light at the top edge by marker number twenty-five. The circuit board has fifteen small circular red condensers, one small brown condenser, and seven orange square shaped condensers. There are also two blueish green colored strip condensers near the top edge. The two black transistors. There are three sets of jumper pins. There are ten resistors or various colors. The circuit board has three black and silver diodes. The circuit board has two metal tabs on the top edge (the one labeled with numbers) that secure the circuit board in place. There is also a blue plastic ribbon harness connector at the top that goes from the thirty-five mark to the sixty-five mark. Along the bottom of the circuit board, there is a long pale colored plastic support that goes from the ten-grid line to the one hundred and twenty grid line, with a separate black section the same length underneath it. There are also fifty-five sections that hold programming information called microchips.

Reviews For 0-54201-2

Internal Review
(5.0)

This 0-54201-2 printed circuit board is a Dual Processor Automate Board manufactured by Reliance Electric for use in one of their many now-obsolete legacy product series. This 0-54201-2 printed circuit board or PCB for short offers two metal tabs at the very top of its base circuit board for installation purposes, and is available here at AX Control today with both repair and replacement options ready. - AX Control Lead Technician

  • O-54201-2

Repair Services For 0-54201-2

Type Lead Time Price Action
Repair Service 1-2 weeks $399

Our highly skilled technicians can repair your 0-54201-2. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
