The 0-52859-2 is a Reliance Digital Voltage Source Sequence Board VSDC

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-52859-2 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-52859-2
  • SKU: 0528592RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-52859-2

0-52859-2 Digital Voltage Source Sequence Board  VSDC

The 0-52859-2  is a Reliance Electric board component manufactured to be used with various Reliance drive systems.  Reliance boards are sometimes marked as Baldor-Reliance or ABB (Asea Brown Boveri) depending on the year of their manufacture.  The part number remains the same.

The 0-52859-2 functions as a Digital Voltage Source Sequence Board.  It is connected used three screws to a front faceplate with multiple components.  These include a bank of screw connections located in its bottom half, three green LED indicators, and a single red LED indicator.  The red LED is labeled IET. The green LEDs are labeled Run, Fwd/Rev, and Fl. The front faceplate also has two screw connections that allow the component to lock into place within the rack system.

The board portion of the  0-52859-2 is populated with four relay components.  Each of these has a relay diagram printed on its top surface.  The board has twenty-two integrated circuits, including inverter chips and high-performance analog operational amplifiers.   Other components include transistors, metal film resistors, diodes, ceramic capacitors, and ceramic disk capacitors. Reference designators are rarely used on this PCB; instead, the surface of the board is printed with a grid pattern across the entire surface of the board.   The rear edge of the circuit board extends in a sort of tail covered in conductive tabs. This functions as a type of backplane connector.

More information regarding the operation and installation of the  0-52859-2 may be found through Reliance publications like manuals, data sheets, or user guides. Please follow all manufacturer recommended handling and safety precautions.
