Reliance Electric CCC Board

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-52840-57 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-52840-57
  • SKU: 05284057RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

0-52840-57 Technical Specifications

Original Manufacturer Reliance Electric
Product Number 0-52840-57
Product Description Power Connect Board
Device Status Now-Obsolete Legacy

About the 0-52840-57

0-52840-57 CCC Card

The 0-52840-57 is a board component fabricated by Reliance Electric.  This circuit board is used in Reliance drive systems. While this circuit board typically originates from Reliance, in some cases, the manufacturer may be either Asea Brown Boveri or Baldor-Reliance.  “52840-57” will always appear in the part id.

The 0-52840-57 is a rectangular circuit board with a conductive backplane connector and an attached faceplate.  The faceplate of the 0-52840-57 has eight rotary dial components placed in its surface. These are each individually labeled.  The front panel also includes two set screws, top and bottom, that lock the module into place once it is inserted into a rack system.

The board portion of the 0-52840-57 is sparsely populated with components.   The board has several diodes and metal film resistors. It has two large polyester vinyl capacitors and several smaller capacitors.  The rest of the board is primarily populated by brass vertical pin connectors. Some components are marked with reference designators, but others only carry their manufacturer part numbers.

Please refer to Reliance publications (manuals or user guides) for detailed information about the operation of the 0-52840-57.  The same publications will have information regarding proper installation procedures, as well as handling and safety guidelines.   Reliance Electric provided all original technical support for the 0-52840-57.

Located in central North Carolina, AX Control maintains our own warehouse of industrial automation parts from Eurotherm, Horner, GE, Cognex Vision, Fuji, and many other manufacturers.  Most of our ‘in stock’ products will ship to you from our location the same day you place your order. Please speak to our team for more information.

Reviews For 0-52840-57

Internal Review
(5.0)

This 0-52840-57 printed circuit board product offering from Reliance Electric is something of a mysterious device, as its sole functional product description attainable online is that of a CCC Card. While this 0-52840-57 printed circuit board may not exist as the most explicitly-defined product, it is well-supported through its possession of a backplane connector and numerous brass pin connectors. - AX Control Lead Technician

  • O-52840-57

Repair Services For 0-52840-57

Type Lead Time Price Action
Repair Service 1-2 weeks $291

Our highly skilled technicians can repair your 0-52840-57. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
