This 0-51422 PCB Drive was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 0-51422 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-51422
  • SKU: 051422RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

0-51422 Technical Specifications

Manufacturer Reliance Electric
Part Number 0-51422
Functional Description PCB Drive
Part Status Now-Obsolete Legacy

Product Description

The 0-51422 is a printed circuit board from Reliance. The circuit board has twelve metal tabs along the bottom edge. The tabs are split into pairs and labeled as follows 1THY (G-50 WH, K-51 RED), 4THY (G-52 WH, K53 RED), 2THY (G-54 WH, K-55 RED), 5THY (G-150 WH, K151 RED), 3THY (G-152 WH, K153 RED), and 6THY (G-154 WH, K-155 RED). These metal tabs are used to connect either white or red wires to the circuit board. The top edge of the circuit board is labeled with numbers zero, five, ten, fifteen, twenty, twenty-five, thirty, thirty-five, forty, forty-five, fifty, fifty-five, and sixty. Above the numbered grid is a small tab with twenty-two traces on it to connect into the drive. The left side of the circuit board is labeled A through Z then AA, AB, AC, AD, AE, AF, AG, AH, AJ, AK, AL, AM, and AN. The labels on the top and left side of the circuit board allow for simple measurement and installation into your system. The circuit board has six transformers near the bottom edge. Above each transformer is a transistor (six in total). There are eight large orange capacitors, six large yellow polypropylene capacitors (with their capacity written on the outside), six smaller yellow polypropylene capacitors (with their capacity written on the outside), twenty-four red capacitors (with their capacity written on the outside),six integrated circuits, twenty-four various resistors (banded components), thirty bead shaped diodes, and eighteen black and silver diodes.

Call AX Control for additional information.

  • O-51422

Repair Services For 0-51422

Type Lead Time Price Action
Repair Service 1-2 weeks $357

Our highly skilled technicians can repair your 0-51422. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
