Product Description
Reliance is the maker of the 0-51419 circuit board. This circuit board is laid out like a grid. It features six square white colored transformers and six circular black transformers equally spaced out across the circuit board. All the transformers are labeled with 2X, 1X, H2, H1, across the tops of them. The circuit board has three black “U” shaped brackets that go down the center of the board. If you were to fold the circuit board in half where these “U” shaped brackets are you would have a mirrored image of the circuit board on each half as far as the components on the circuit board are concerned, the labeling written on the surface would be off, however. The circuit board has the alphabet written from one end to the other A through Z then AA, AB, AC, AD, AE, and AF. There is also a tallied line going in the opposite direction of the alphabetic markings from zero to sixty with larger markings in increments of five. This line, however, is split to accommodate the components on the circuit board. There are six metal tabs labeled with both the letter “G” and the abbreviation WHT (for white) and six metal tabs labeled with the letter “K” and the word RED. The colors for each it so the engineer will know what type and color of wire to attach to the metal tabs.
If you would like to find out more about the 0-51419 circuit board or receive a quote to purchase one, reach out to the skilled staff of AX Control.
