0-51381-13

About the 0-51381-13

The 0-51381-13 is a PC Controller circuit board made by Reliance. This PC Controller circuit board has twelve small silver screws separated by black dividers. These screws are used to secure different wires to the circuit board. The 0-51381-13 has a large transformer on the right side of the circuit board. There are eight various colored wires attached to the transformer. The circuit board has a few transistors that amplify energy flowing around the circuit board. The 0-51381-13 also has some capacitors to store energy, resistors to rid the circuit board of energy, diodes to direct energy flow. The 0-51381-13 has nine metal tabs that are used to also attach various wires between circuit boards. The metal tabs are labeled from left to right as follows 45, 32, G2, G1, 47, 182, 181. The circuit board’s surface is mapped out in a grid-like pattern. The edges of the grid where the lines are are labeled with various numbers. These numbers allow for the circuit board to easily be installed into the drive you need the circuit board for. To secure the circuit board once installed you can use the predrilled holes around the circuit board.  Along with the grid-like pattern on the circuit boards surface, there are also smaller shapes drawn into the grid pattern that go around other components of the circuit board like, the transistors. There are also four circles drawn across the top three of which have a metal circular piece in the center and each one is labeled.
