This 0-51378-12 Gate Coupling Board was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a 0-51378-12 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-51378-12
  • SKU: 05137812RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-51378-12

The 0-51378-12 is a Gate Coupling Board constructed by Reliance Electric. This board may have also been manufactured by ASEA BROWN BOVERI, Allen Bradley, or Baldor Reliance depending on the year it was in production.

The 0-51378-12 is a printed circuit board that can be used as a diode substitution. This coupling board can be used with an 86475-11S Rectifier Stack. The 0-51378-12 is made up of several key parts including wired connectors, diodes, terminal pins, and dual resistors. This card is attached to the top of a heat sink on the rectifier stack or phase rectifier module. A rectifier stack is a device used to convert unpredictable AC current to a more manageable one-way flowing DC current. It does this by using a pair of thyristors to pulse at a specific point in the AC power cycle.

More information about the 0-51378-12 and the rectifier stack it attaches to can be found in the original Reliance Electric product manuals. Please refer to them before trying to attach the 0-51378-12 to its rectifier. Only a qualified professional should install this board.

If you would like an official price quote or for quotes about shipping costs for the 0-51378-12 from AX Control, please email or call us at 1-919-372-8413. Emails typically take 15 minutes to answer during normal business hours. Please contact us directly if you have any questions about the compatibility of the 0-51378-12 with your system. We are here to help make your repair process as smooth as possible.

Reviews For 0-51378-12

Internal Review
(5.0)

This 0-51378-12 printed circuit board developed and produced by Reliance Electric fits well within its functional role as a Gate Coupling Board; one of the most frequent Reliance Electric legacy series product functionalities. This 0-51378-12 Gate Coupling Board can be used as a diode substitution, and is considered available today here with both repair and replacement options at the ready. - AX Control Lead Technician

  • O-51378-12

Repair Services For 0-51378-12

Type Lead Time Price Action
Repair Service 1-2 weeks $357

Our highly skilled technicians can repair your 0-51378-12. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
