This 0-49046 Cardpak Amplifier was manufactured by Reliance Electric.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 0-49046 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-49046
  • SKU: 049046RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

0-49046 Technical Specifications

Manufacturer Reliance Electric
Part Number 0-49046
Functional Description Cardpak Amplifier
Device Status Now-Obsolete Legacy

Product Description

The  0-49046 is a Cardpak Amplifier unit designed by Reliance Electric.  This part was also sold under the company name Asea Brown Boveri; however, it is no longer available through the OEM.  We typically have this item in stock here at AX Control.  Please check our online stock notices or with our staff to verify our current stock levels.

The 0-49046 is designed to transform a control signal--typically from a motion controller--into a higher power voltage for a connected actuator.    The CardPak series is similar to Reliance’s MaxPak and ImPak series of parts.

The  0-49046 component is designed within an external plastic carrying case that is designed with tophat flanges along its bottom edges.  These flanges include two vertical pins that will help to connect and keep the unit properly positioned after installation.

The front faceplate of the  0-49046 includes two rotary dials that can be set along a range from zero to ten.  These dials are marked “gain” and “zero set.”  The board also includes the Reliance name and logo, the CARDPak name, and the part number.  The bottom edge of the case is open to allow access to internal circuit boards and to allow for proper air flow.

Additional information regarding installation and handling of this component can be found using documentation from Reliance, including manuals and user guides.  If you no longer have access to your original documentation, AX Control may be able to help with replacements.  Please check about this option when you place your order.  Our staff is happy to assist you.

Reviews For 0-49046

Internal Review
(5.0)

This 0-49046 Reliance Electric product offering was manufactured for placement in one of the trusted manufacturer's now-obsolete legacy series, specifically to exist as a CardPak Amplifier Board as described before. This 0-49046 device belongs to the CardPak product subseries, a fact made obvious by various factory-printed labels. This 0-49046 PCB is available today for repair or replacement. - AX Control Lead Technician

  • O-49046

Repair Services For 0-49046

Type Lead Time Price Action
Repair Service 1-2 weeks $258

Our highly skilled technicians can repair your 0-49046. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
