This 0-48652-30 Calibration Meter Board was manufactured by Reliance Electric.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 0-48652-30 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 0-48652-30
  • SKU: 04865230RE
  • Manufacturer: Reliance Electric
  • Series: Drive Boards

About the 0-48652-30

The 0-48652-30 is a Calibration Meter Board created by Reliance Electric. The 0-48652-30 has a front panel that has four variable resistor knobs coming through. The top variable resistor knob is labeled CRAWL SPD REF., and the knob has the numbers zero through ten on it. The second variable resistor knob is labeled CURRENT COMP. and the knob has the numbers zero through ten on it. The third variable resistor knob is labeled MAX. SPD. and the knob has the numbers zero through ten on it. The fourth variable resistor knob is labeled SLACK TAKE UP and the knob has the numbers zero through ten on it. The circuit board has another small variable resistor on it with only a small screw to adjust it. The 0-48652-30 has well over one hundred metal pins (each pin has a small circle around the base and a customized label for what that pin is used for). These metal pins are used as relays to connect various components to the circuit board without having to make traces or having to solder the parts. All that must be done is to wrap the wire from the piece around the pegs. Between the sections of metal pins are also positive and negatively labeled arrows. There are four places for integrated circuits on the bottom right side. There is also two radial ceramic capacitors and a carbon composition resistor that are connected directly to the circuit board.

For a quote contact the friendly staff at AX Control today.

Frequently Asked Questions about 0-48652-30

Have any factory-drilled holes been made in the base circuit board of this 0-48652-30 product?

Yes. The base circuit board of this 0-48652-30 device has been factory-drilled in several locations to support convenient and safe installation practices.

Would this 0-48652-30 device be protected by any warranty upon my purchase here?

Yes. Immediately upon your original purchase from AX Control, this 0-48652-30 product and many others would be considered protected by our guaranteed three-year warranty.

Reviews For 0-48652-30

Internal Review
(5.0)

This 0-48652-30 Reliance Electric printed circuit board product offering was manufactured to exist in one of their now-obsolete legacy product series. This 0-48652-30 PCB device is actually defined as a Calibration Meter Board in its original Reliance Electric instructional manuals, and offers several standard hardware components including rotary dials and a printed measurement grid. - AX Control Lead Technician

  • O-48652-30

Repair Services For 0-48652-30

Type Lead Time Price Action
Repair Service 1-2 weeks $293

Our highly skilled technicians can repair your 0-48652-30. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
