Rockwell Automate DCS 5000 Dual Output 24V 2A Module.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C63 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C63

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.78 (9)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.78 (9)
  • Click a star to rate this product
Rockwell Automate DCS 5000 Dual Output 24V 2A Module.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a 45C63 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

45C63 Technical Specifications

Instruction Manual J-3012
Manufacturer Reliance Electric
Part Number 45C63
Product Type Dual D-C Output Module
Series AutoMax PLC

Product Description

The 45C63 unit is an AutoMax Dual DC Output Module that was designed by Reliance Electric. Although the 45C63 output module is no longer produced by the original manufacturer, AX Control may have it in stock, as notated by our website. If you have any questions, send us an email or give us a call.

The 45C63 output module is one in a group of three dual DC output modules. The other two have more Volts than this particular module, which has a total of 24 Volts. There is the 45C65 output module, which has a rating of 115 Volts, and the 45C68 output module, which has a rating of 250 Volts. Follow the links associated with these products to find their pages on AX Control’s website, which will further detail their specifications.

The 45C63 output module has a nominal DC voltage of 24 Volts and the working voltage ranges from 15 Volts to 40 Volts. In addition to that, the allowable peak voltage due to overshoot is 100 Volts. As for the output circuit of the 45C63 output module, the maximum continuous output current is set to 2 Amps, the maximum on-state Voltage is 0.8 Volts, and the maximum off-state leakage current at peak Voltage is 1 milliAmp. In addition to that, the maximum inductive load energy is 6.5 Joules and the power dissipation at maximum temperature and current is 2.6 Watts.

For proper use of the 45C63 output module, plug it into an I/O rail, such as the AutoMax 45C1 model. After installation, be sure that the environmental conditions of the area it is in are sound. The operating temperature at the module must be between 32 degrees and 140 degrees Fahrenheit, the storage temperature must be between -4 degrees and 185 degrees Fahrenheit, and the humidity must be between 5% and 90% non-condensing.

The 45C63 output module has a total weight of approximately 0.31 lbs. or 0.14 kg.

Frequently Asked Questions about 45C63

What does 45C63 do?
45C63 uses low-level logic signals to switch power circuits by driving a FET to switch a load. 45C63 has two switched outputs to do this.
Is 45C63 the only dual D-C output module?
No. 45C63 is one of three dual D-C output modules. Besides 45C63, model numbers 45C65 and 45C68 are dual D-C output modules.
What power does 45C63 operate on?
45C63 has a 24 VDC operating power.
Where can I get the manual for 45C63?
We're happy to send you the manual for 45C63. The manual is Manual J-3012, the AutoMate DCS 5000/AutoMax Digital I/O Rails and Modules Manual. Information on 45C63 is in section 3.6 of the manual.
