The GP-4503T HMI has a 640 x 480 10.4 Inch TFT LCD Touch Panel with two COM ports (RS-232C and RS-422/485) and 32 MB of Flash EPROM memory

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a GP-4503T to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GP-4503T

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
The GP-4503T HMI has a 640 x 480 10.4 Inch TFT LCD Touch Panel with two COM ports (RS-232C and RS-422/485) and 32 MB of Flash EPROM memory

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a GP-4503T to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GP-4503T Technical Specifications

Display Color 65,536 Colors
Display Type TFT Type Color LCD
Global Code PFXGP4503TAD
Input Voltage DC24V
Manufacturer Pro-Face
Resolution 640 x 480 dots (VGA)
Screen Size 10.4-inch
Software Version GP-Pro EX

Product Description

The Proface GP-4503T is a Proface Xycom (now Schneider Electric) touch panel HMI.  This unit has a rated DC24V input voltage with an input voltage limit between 19.2 and 28.8 volts.   The GP-4503T has an allowable voltage drop of 10 ms or less and has a power consumption of 17 watts max.    This unit may also be listed or sold as Proface PFXGP4503TAD.

This HMI touch panel uses natural air circulation cooling.  Mount in locations free from corrosive gases where the surrounding air temperature remains between zero to 55 degrees Celsius in 10 to 90% relative humidity, non-condensing.   This unit is not recommended for use above 2,000 meters as air pressure tends to be out of range for this unit.

The GP-4503T has a replaceable lithium battery located in its rear panel. The unit is built with a single SD card slot, two COM ports (RS-232C and RS-422/485), an Ethernet port, and two USB ports.  One USB is a Type-A while the other is a mini-B.    The GP-4503T is built with an analog resistive film touch screen.  The unit has sixteen brightness and contrast levels.  These can be adjusted through the touch panel.  Backup memory is limited to 321 kb SRAM with a backup battery (replaceable).   The unit has an additional 32 MB of Flash EPROM memory.

Our company works hard to maintain onhand stock of as many Proface HMIs as we possibly can so we can fulfill your orders as quickly as possible.  If this particular model doesn’t meet your requirements, please look through our extensive offerings to see if another model is available.


Reviews For GP-4503T
Internal Review

The Proface GP-4503T is also listed on our site as Model number PFXGP4503TAD. This 10.4-inch TFT LCD HMI VGA touch panel has a user-replaceable battery. Make sure to follow OEM directions for this operation, including finishing the swap out in ten minutes or less.--AX Control Tech Team.

Repair Services For GP-4503T

Type Lead Time Price Action
Repair Service 1-2 weeks $541

Our highly skilled technicians can repair your GP-4503T. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

GP-4503T Manuals, White Papers, Data Sheets, and Troubleshooting
