The PFXGP4503TAD Operator Interface by Xycom, a subsidiary of Pro-face, features a 10.4-inch TFT Analog Color LCD Display 24VDC rated for UL/CE standards

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXGP4503TAD to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXGP4503TAD

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product
The PFXGP4503TAD Operator Interface by Xycom, a subsidiary of Pro-face, features a 10.4-inch TFT Analog Color LCD Display 24VDC rated for UL/CE standards

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXGP4503TAD to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXGP4503TAD Technical Specifications

Dimensions Width: 10.75 inches Height: 8.50 Inches Depth: 2.25 Inches
Display Color 60,000 Colors
Display Type TFT Type Color LCD
Features RS-232C and RS-485 (Isolation)
Input Voltage V24DC
Manufacturer Pro-Face
Model Number PFXGP4503TAD
Resolution 640 x 480 dots (VGA)
Screen Size 10.4-inch
Software Version GP-Pro EX
Storage Temperature -4 to 140 Degrees Fahrenheit
Weight 2 Kilograms

Product Description

PFXGP4503TAD is a Schneider Electric Pro-Face touch panel display interface. DC 24 V is the rated input voltage, DC 19.2 to 28.8 V is the input voltage limit, 10 ms or less is the allowable voltage drop, 17 watts or less is the power consumption, 30 A or less is the in-rush current, and AC 1000 V 20 mA for 1 minute is the voltage endurance. DC 500 V, 10 MΩ or more is the insulation resistance. 0 to 55°C is the surrounding air temperature (recommended) and -20 to 60°C os the storage temperature (recommended). 10 to 90% is the recommended ambient and storage humidity for this unit. Pollution Degree 2 is the environment requirement for this unit. The atmosphere must be free of corrosive gases. 800 to 1114 hPA is the air pressure range.

The altitude range maxes out at 2000 m. The vibration resistance is IEC/EEN61131-2 compliant. The concussion resistance is IEC/EN61131-2 compliant. The contact discharge method is 6 kV (IEC/EN61000-4-2 Level 3). The approximate weight of this unit is 2 kg. One million times is the touch panel service life. The clock accuracy is ± 65 seconds per month. This deviation in the clock accuracy occurs at room temperature and when the power is off. The variable area is SRAM 64 KB, the data backup is SRAM 320 KB, and the font area is FLASH EPROM 8 MB. There is a replaceable lithium battery for backup memory. The touch panel is a resistive film type.

Reviews For PFXGP4503TAD
Internal Review

The PFXGP4503TAD can simultaneously support up to four protocol drivers. The TFT color 10.4 inch HMI has a resistive film analog touch screen with 1024 x 1024 resolution. It can provide users with clear part images on its bright, display with up to 65k colors. The unit is CE marked and UL Listed. --AX Control Tech Team.

Repair Services For PFXGP4503TAD

Type Lead Time Price Action
Repair Service 1-2 weeks $489

Our highly skilled technicians can repair your PFXGP4503TAD. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
