The IO_C Input Module was made for General Electric's Multilin Product Series.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a IO_C to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IO_C
  • SKU: GM-52045
  • Manufacturer: GE Multilin
  • Series: MM300 Motor Manager

IO_C Technical Specifications

Manufacturer General Electric Multilin (GE)
Manufacturing Location Markham, Ontario, Canada
Software EnerVista MM300
Model Number IO_C
Cute Little Face (IO_C)

About the IO_C

Greater Product Series Details

This device is a component module that was developed and produced as a part for the MM300 line of motor control units. General Electric was the manufacturer for these parts, and they are also available from our inventory of both used and new surplus hardware.

The MM300 series is:

  • a GE Multilin line of devices
  • built for motor protection and control
  • designed for use only on low-voltage motors
  •  able to provide them with several applications and functionalitie
  • flexible with a range of protection, control, and communication functionalities
  • built with a compact, modular design that completely eliminates the need for any additional individual modules

Hardware Tips and Specifications

The IO_C component is a digital input module for a MM300 unit. The IO_C unit has a number of critical hardware components with individual hardware specifications that all reveal this IO_C device's intended GE Multilin Series functional role. Some of these IO_C Device hardware qualities are stored in chart form below

IO_C Digital Input Module
form-A relays Two 10 A
Digital inputs Six 60 to 300 V/AC Inputs
Auxiliary Module VT Input
Base Attachment Series MM300
Fixed Pickup Up to 65 V
Recognition Time Max 2 Cycles

The current draw at a rated voltage of 75 milliamperes at 120 V/AC, or 60 mA at 240 V/AC. The input impedance is 1.7 kilo ohms. The max input voltage this unit can withstand is 300 V/AC.

AX Control Inc. is able to provide the IO_C and other GE Multilin units, in our inventory of industrial hardware. We offer an automatic protective warranty that goes into effect upon purchase.


Frequently Asked Questions about IO_C

What is the IO_C part?

Produced by General Electric Multilin, the IO_C unit is a module that contains two form-A contact output relays, six digital inputs, and control voltage input. The two form-A contact output relays can be configured to a number of digital signals, such as status signals, alarms, and more. The six digital inputs can be programmed to any of the input processes, i.e. process interlock or field stop.

How do users program the digital inputs and contact outputs once wiring is completed?

For users who have purchased a relay with a liquid-crystal display on the faceplate of the device, users can manually program these settings using the keypad and the faceplate in tandem. However, programming is considerably more efficient using the EnerVista MM300 software program, which offers a streamlined interface and a graphical drag-and-drop environment for setpoint editing.

Reviews For IO_C

Internal Review
(5.0)

The IO_C module is capable of sensing an interruption to its auxiliary supply, in which case it is able to initiate an AC Low Aux Voltage Inhibit. This protective process forces the input state of the contact inputs to the OFF setting, as actual states and parameters cannot be sensed. - AX Control Tech
