Part of the MMII product line, GE Multilin's MMII-PD-1-2-MOD616-120 is motor management system with a faceplate featuring an LCD, keypad, and more.



Sell Surplus: Have a MMII-PD-1-2-MOD616-120 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: MMII-PD-1-2-MOD616-120
  • SKU: MMIIPD12MOD616120GM
  • Manufacturer: GE Multilin
  • Series: MM2 Motor Manager

MMII-PD-1-2-MOD616-120 Technical Specifications

Model Number MMII-PD-1-2-MOD616-120
Manufacturer GE Multilin
Manufacturing Location Ontario, Canada
Shipping Dimensions 211 mm x 143 mm x 147 mm
Shipping Weight max. 4 lbs
Software EnerVista
Ground Fault Current Input Conversion True RMS, sample time 1.67 ms
Pollution Degree II
Communication Type RS485 2-wire, half duplex
Max Continuous Voltage 280 V AC

Product Description

This piece of industrial technology is a part of the Multilin MM 2 series, from General Electric. The Motor Manager 2 series from GE Multilin was built to provide efficient reports, relaying, as well as protecting the equipment it’s reporting on at a reduced price compared to other devices. As intelligent MCC Controllers, these models are outfitted to be the most efficient devices of their class, combining controlling functions and motor protection functions in one compact unit, reducing the need for auxiliary metering and control equipment.

The MMII-PD-1-2-MOD616-120 model is built to handle issues such as overload and phase imbalances. Should a motor contactor fail, a rotor become out of place or locked/stalled, then this module is capable of overriding these conditions and ensuring that they resolve themselves. The unit can also trigger alarms that alert operators to the problem.

This model is outfitted with a series of integrated hardware that allows more efficient and expanded range of action and monitoring. Contained in this unit is a winding thermistor circuit and an undervoltage automatic restart module. The winding thermistor input alters the electric input should a significant change in temperature occur, while the undervoltage automatic restart module restarts unit processes to achieve the appropriate nominal power intake.

The MMII-PD-1-2-MOD616-120 is externally integrated with up to 20 I/O ports: 4 outputs and 16 outputs. The output ports are composed of a pair of contactor outputs and a pair of programmable outputs. The inputs are made of 6 fixed input ports and up to 10 programmable inputs.

Frequently Asked Questions about MMII-PD-1-2-MOD616-120

What does the “MOD616” in the MMII-PD-1-2-MOD616-120’s model number refer to?

This version of the MM2 possesses a remote display feature, allowing users to view system processes at a location of their choice instead of only at the relay’s installed location. Other devices in the series include other modifications, such as the MOD 610, which features a conformal coating that shields the device from dust, chemical corrosion, and extreme temperatures. The MOD614 version of the device features a VT primary setpoint up to 7200 V and variable overload curve setting. Users can peruse the MMII user manuals to find and choose the best option for their power system.

What do the two option packages included in the MMII-PD-1-2-MOD616-120 provide?

The first option package increases the number of management and diagnostic features available to the MMII-PD-1-2-MOD616-120; it adds process control and process inputs, undervoltage auto restart capabilities, and enhanced diagnostics such as alarms and pre-trip data. The second option package raises the amount of protective features and input options, supplying the device with a second contactor control (which includes two control inputs), more protective features, and a motor winding thermistor input.

Reviews For MMII-PD-1-2-MOD616-120

Internal Review

The MMII-PD-1-2-MOD616-120’s programmable alarms can alert users to hazardous conditions within the motor system; some of these hazardous conditions include exceeded acceleration time, abnormal inverter starting, incomplete start, and motor greasing. - AX Control Tech
