Offering a full faceplate with a liquid-crystal display, GE Multilin's MMII-PD-1-2-120 is a motor management unit designed to protect and manage motor systems.



Sell Surplus: Have a MMII-PD-1-2-120 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: MMII-PD-1-2-120
  • SKU: MMIIPD12120GM
  • Manufacturer: GE Multilin
  • Series: MM2 Motor Manager

MMII-PD-1-2-120 Technical Specifications

Model Number MMII-PD-1-2-120
Manufacturer General Electric Multilin (GE)
Manufacturing Location Markham, Ontario, Canada
Dimensions approx. 7.4” L, 4.4” H, 5” W
Weight 3 lb (1.36 kg)
Software EnerVista MMII
Operating Temperature Range 0° C to 60° C
Analog Input Range 4 – 20 mA
Single Phase Accuracy ±2 percentage points
Communications Baud Rate 1,200 bps – 19,200 bps

Product Description

This module is the MMII-PD-1-2-120, a model of the Motor Manager II series from General Electric Multilin. These units were produced and developed initially by the industrial automation branch of GE, and have long since been out of production. Fortunately, our technicians at AX Control have skillfully refurbished and optimized our inventory to run as efficiently and smoothly as possible.

The MMII-PD-1-2-120 unit is a motor control center. This module combines several comprehensive functions regarding control and motor protection. This device is built with a compact frame but is still outfitted with the capacity to provide advanced protective relaying at a lower cost than similar, less effective models.

This unit, as well as the other models in the Motor Manager II series, is built to handle numerous tasks and react quickly if any events occur. It can protect from a possible overload or an unbalanced phasing. Should a contactor fail or a rotor becomes locked and/or stalled, then this unit can detect and run routines to get it under control. The unit is also outfitted with a hot winding thermistor circuit. If the model is receiving a power intake that is below the nominal threshold, this unit is equipped with an undervoltage auto restart.

The display capabilities of this model enable it to show phase and ground current, thermal capacity, and energy levels. These parameters can be viewed through the LCD or through Multilin's EnerVista MMII software program.

Once purchased, the MMII-PD-1-2-120 model, as well as the rest of AX Control’s wide inventory, is covered by our extensive, protective warranty for up to 3 years (depending on the product classification).

Frequently Asked Questions about MMII-PD-1-2-120

How does the MMII-PD-1-2-120 create cost benefit for the buyer?

The MMII-PD-1-2-120 contains a variety of functions in one compact device, removing the need for expensive auxiliary equipment and wiring, such as extraneous metering or protective machinery. The modular, cost-effective design also reduces the price considerably compared to units with similar functions and purposes.

What are the components of the faceplate of the device? How do they assist the user during routine operation?

The faceplate of the device holds the liquid-crystal display, keypad, a variety of LED indicators, and the emergency STOP/trip pushbutton. The liquid-crystal display is viewable under a variety of conditions and features two lines of alphanumeric content. It can be programmed to passively display system parameters for nearby users. The keypad can be utilized to navigate the LCD and adjust settings manually. The LED indicators reflect system processes in-progress, such as when alarms are triggered within the system. Lastly, the STOP pushbutton can halt system function and acts as a failsafe for when users need to manually shut down the power system.

Reviews For MMII-PD-1-2-120

Internal Review

The ports of the MMII-PD-1-2-120 can be slightly difficult to access; users should take care and employ precision when making connections for the unit. Otherwise, the MMII-PD-1-2-120 relay is an excellent choice for motor management and protection. - AX Control Tech
