Product Description

350-E-P5-S5-H-E-S-N-P-1E-N-H is a microprocessor-based relay that is manufactured by GE Multilin for the 350 Feeder Protection System series. This 3-phase relay has 5 amp current inputs and a 5 amp sensitive ground current input. The language of this system is English. The power supply is 24 to 28 VDC. This relay has a standard faceplate with 10 inputs and 7 outputs. The current protection has a standard configuration. There is a harsh environment conformal coating on this unit. There is also a standard communication port and an Ethernet port.

The order codes for this series provide the user with information about the part. “350” indicates that the part is from the 350 Feeder Protection System series by GE. The next digit indicates the language, wherein C = Chinese and E = English. The next two digits indicate the phase currents, wherein P1 = 1 A 3-phase current inputs and P5 = 5 A 3-phase current inputs. The next two digits indicate the ground currents, wherein G1 = 1 A ground current input, G5 = 5 A ground current input, S1 = 1 A sensitive ground current input, and S5 = 5 A sensitive ground current input. The next digit is the power supply, wherein L = 24 to 28 VDC and H = 125 to 250 VDC and 120 to 240 VAC. The next digit is the faceplate and the contact inputs, wherein S = standard faceplate with 8 inputs and 7 outputs, and E = standard faceplate with 10 inputs and 7 outputs. The next digit is the current protection, wherein S = standard configuration, E = extended configuration, and M = advanced configuration. The next digit is the control, wherein N = no selection, P = voltage protection, neutral and ground directional elements, D = neutral and ground directional elements, M = voltage metering, and R = neutral and ground directional elements, voltage metering. The next two digits are the communications features, wherein SN = Standard: Front USB, Rear RS485: Modbus RTU, DNP3.0, IEC60870-5-103; 1E = Standard + Ethernet, Modbus TCP/IP, DNP3.0, IEC60870-5-104; 2E = Standard + Ethernet, Modbus TCP/IP, DNP3.0, IEC60870-5-104, IEC 61850 GOOSE; and 3E = Standard + Ethernet, Modbus TCP/IP, DNP3.0, IEC60870-5-104, IEC 61850. The next digit is a placeholder D. The last digit is the harsh environment protection, wherein N = none and H = harsh environment conformal coating.



More information regarding the use and installation of this feeder protection device can be sourced through GE manuals and GE user guides.

Frequently Asked Questions about 350-E-P5-S5-H-E-S-N-P-1E-N-H

What are the order codes of the 350 Multilin feeder protection device 350-E-P5-S5-H-E-S-N-P-1E-N-H?
The 350-E-P5-S5-H-E-S-N-P-1E-N-H is unique to other 350 Multilin feeder protection devices because it includes a harsh environment conformal coating option (option H). This allows for advanced protection of the device over time in harsh environmental operating conditions. The Multilin 350-E-P5-S5-H-E-S-N-P-1E-N-H also has 5A three phase current inputs. The device is unique in that it has a S5 designation for ground current. This order option (S5) specifies that the feeder protection device has a 5A sensitive ground current input.
What type of current protection, control, communication options, and other features does the feeder protection device 350-E-P5-S5-H-E-S-N-P-1E-N-H have?
The 350-E-P5-S5-H-E-S-N-P-1E-N-H GE Multilin protection device has a high (H) power supply with a 125-250 VDC range and a 120-240 VAC range. The standard faceplate of the unit comes with a full menu and an LCD with 10 inputs and 7 outputs as does other 350 Multilin feeder protection devices. The 350-E-P5-S5-H-E-S-N-P-1E-N-H has the standard overcurrent protection (other options are extended overcurrent protection and advanced overcurrent protection). This device does not have a selection for the specific control (N). The communication option specified for this feeder protection device is designated by (P) as including a voltage protection option.
