The 350-E-P0-G0-H-E-E-N-N-SN-N-N model is one of the Feeder Protection Systems produced by GE Multilin. This model has extended overcurrent protection. The 350-E-P0-G0-H-E-E-N-N-SN-N-N relay also features a standard USB in the front with an RS485 port on the rear of the model.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 350-E-P0-G0-H-E-E-N-N-SN-N-N to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 350-E-P0-G0-H-E-E-N-N-SN-N-N
  • SKU: 350EP0G0HEENNSNNNGM
  • Manufacturer: GE Multilin
  • Series: 350 Feeder Protection System

350-E-P0-G0-H-E-E-N-N-SN-N-N Technical Specifications

Autoreclose Reclose Attempts Maximum of 4 Shots
Case Design Protection Relay with Non-Drawout Design
Frequency Range 40.00 to 70.00 Hertz
Harsh Environment Coating Not Available
Master Reset Password 8-10 Alphanumeric Characters
Number of Events Recorded Up to 256
Oscillography Buffer Size 3 s
Sensitive Ground Time Overcurrent Pickup Level 0.005 to 3 x CT in steps of 0.001 x CT

Product Description

The Feeder Protection System Relay 350-E-P0-G0-H-E-E-N-N-SN-N-N was produced by GE Multilin to operate as a relay model without any programmable light-emitting diodes (LEDs). The customary faceplate of this model has both inputs and outputs, there are ten inputs used with this model and there are seven outputs. The current protection used with this model has an extended configuration.

According to the order code within one of the General Electric publications, the 350-E-P0-G0-H-E-E-N-N-SN-N-N model has standard communications features. The associated communications are a USB on the front of the device with an RS485 communication port on the backside. Please note that the RS4858 port is a Modbus RTU, with IEC60870-5-103, DNP3.0 standards.

There are a wide variety of protection features available on the 350-E-P0-G0-H-E-E-N-N-SN-N-N relay device some of which are as follows:

  • Auxiliary Undervoltage designated by ANSI device 27X

  • Phase Voltage designated by ANSI device 59P

  • Cold Load Pickup designated by ANSI device CLP

  • Neutral Directional Element designated by ANSI device 67N

  • Negative Sequence Overvoltage designated by ANSI device 59_2

All of these features are just a few of the many protection features that are offered with this relay device. For more protection features refer to the GE Multilin 350 Instruction Manual which has not only extensive information on the protection features but information on the part breakdown and its codes available as well.

There are two interfaces available with the 350-E-P0-G0-H-E-E-N-N-SN-N-N relay which are either interfacing through the EnerVista SR3 Setup Software or through the relay keypad and display. Chapter three of the GE Multilin 350 Instruction Manual will provide more extensive information about these two interfaces.

Frequently Asked Questions about 350-E-P0-G0-H-E-E-N-N-SN-N-N

What features does the 350-E-P0-G0-H-E-E-N-N-SN-N-N offer as a Multilin 3 Series 350 Multilin GE feeder protection device.
The 350-E-P0-G0-H-E-E-N-N-SN-N-N is a member of the Multilin 350 series and functions as an innovative feeder protection device. The 350 Multilin offers a design for different voltage applications (low, medium, or high). The 350-E-P0-G0-H-E-E-N-N-SN-N-N specifically has a high power supply (H). The 350 Multilin is able to provide the user with metering and monitoring features, diagnostics, preventative maintenance capabilities, and communications and security features depending on the specific order codes present in the specific 350 Multilin.
What order specifications are indicated for the 350-E-P0-G0-H-E-E-N-N-SN-N-N Multilin 3 Series 350 Multilin GE feeder protection device?
The innovative 350-E-P0-G0-H-E-E-N-N-SN-N-N Multilin 3 Series 350 Multilin GE feeder protection device has the standard faceplate. This faceplate includes a full menu, LCD, and actual value and setpoint visualization. The unit has 10 inputs and 7 outputs. Two of these are form A and five of these are form C. The 350-E-P0-G0-H-E-E-N-N-SN-N-N Multilin has the extended overcurrent protection option. These specifications are extended from the standard option. The specifics of this option are as follows: 49, 50P(2), 50G(2), 50N(2), 51P(1), 51G(1), 51N(1). The 350-E-P0-G0-H-E-E-N-N-SN-N-N Multilin does not come with the draw out design or the harsh environment conformal coating (N-N).

Reviews For 350-E-P0-G0-H-E-E-N-N-SN-N-N

Internal Review
(5.0)

The two interfaces on this relay allow the user to choose which interface is best suited for their needs. Depending on the chosen interface there are different settings as well. - AX Control Tech Team
