IS210MACCH1A

4.90 (10)
Click a star to rate this product

4.90 (10)
Click a star to rate this product

The IS210MACCH1A Machine Control Interface Board made for General Electric's Mark VI IS200 Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS210MACCH1A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS210MACCH1A
SKU: GBTC-59508

Manufacturer: GE Boards & Turbine Control
Series: Mark VI IS200

Description
Repairs
Warranty
Manuals

IS210MACCH1A Technical Specifications

Functional Part Number	IS210MACCH1A
Series	Mark VI IS200
Manufacturer	General Electric
Primary Functional Revision	A
Assembly Type	IS210 Special Assembly
Functional Product Acronym	MACC
Base PCB Coating	Conformal Coating
Installation Holes	6 Holes
I/O Ports	11 Ports
Terminal Strips	1 Strip
Ethernet Ports	3 Ethernet Ports

About the IS210MACCH1A

The IS210MACCH1A Machine Interface Board featuring here was originally designed for General Electric's Mark VI IS200 Series, with a number of important hardware qualities telling of this series attribution, such as its:

IS210 standard special assembly
MACC functional abbreviation
Conformal base circuitry coating
Group one Mark VI Series grouping
A-rated revision

The sole revision attributable to the IS210MACCH1A is classified as a performance-focused functional revision that does not alter the exterior hardware of the unit. Similarly-named units to the IS210MACCH1A tend to feature an attached daughterboard.

IS210MACCH1A Installation and Communication

A number of individual IS210MACCH1A hardware components aid specifically in installation and communication processes. It is evident that the majority of this IS210MACCH1A's outbound communications will be transmitted via its seriex of three Ethernet ports featured on the front of the unit. Four additional I/O ports exist in two parallel pairs of two ports each.

In terms of installation, it is likely that the IS210MACCH1A has been designed for insertion upon a series of screw standoffs, as numerous insulated drill-holes suggest.

Frequently Asked Questions about IS210MACCH1A

Does the IS210MACCH1A have a normal PCB assembly?

No. Perhaps the unusual thickness of the IS210MACCH1A Board classifies the unit as having an IS210 specila assembly type.

What types of processes is the IS210MACCH1A often involved in?

The IS210MACCH1A PCB/Module here is oftentimes used in alternative energy settings, as proven by its IS210MACCH3A sister product's insertion in the related Mark VIe Wind Series.

Reviews For IS210MACCH1A

Internal Review

(5.0)

The IS210MACCH1A Machine Control Interface Board made for General Electric's Mark VI IS200 Series has a standard assembly has an outer circuit board edge lined with different I/O ports. This does mean that its base PCB has a back with a detailed wiring diagram. The MACC-abbreviated product here is only revised through a standard base rev. - AX Control Lead Technician

Repair Services For IS210MACCH1A

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	Ask	Get Quote

Our highly skilled technicians can repair your IS210MACCH1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.

All PLCs, HMIs, and Turbine Control Boards:	3 Years
All AC/DC and Servo Drives:	2 Years
All Motors:	1 Year
