IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a IS200DTAIH1ABB to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200DTAIH1ABB
  • SKU: GBTC-53556
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark VI IS200

IS200DTAIH1ABB Technical Specifications

Manufacturer General Electric
Series Mark VI Speedtronic
Functional Part Number IS200DTAIH1ABB
Functional Description Simplex Analog Input/Output Terminal Board
Revision Total 3 Revisions
Backwards-Compatibility 1st two revisions
Assembly Type Normal Assembly

About the IS200DTAIH1ABB

The Mark VI has Ethernet communication capabilities and includes onboard diagnostics (limit checking) within both the hardware and the software. The IS200DTAIH1ABB is a Simplex Analog Input/Output terminal board. It is a compact input board for analog signals. The board is mounted into a plastic holder that allows the PCB to be DIN-rail mounted. This board has ten analog inputs as well as two analog outputs. The outputs are 0-20mA but one can be configured for 0-200mA current by reconfiguring jumpers. The IS200DTAIH1ABB has a single 37-pin connector with latching fasteners. This is labeled JR1. The board has a terminal board (TB1) with 48 screw connections. This terminal strip is permanently mounted to the board. Shielded twisted pairs of #18 AWG wire are typically used on the terminal block. Please note that screws 43/44 are designated as the ground (SCOM) connection. The ground wire should be as short as possible. The board has:

  • twenty-one jumper switches
    • labeled JP1A/B-JP10A/B and JP
  • various capacitors, resistors, and integrated circuits
  • four small sub-panels
  • jumpers on the board
    • used to configure current and voltage

IS200DTAIH1ABB Device Catalog Number Insights

Technical support for the IS200DTAIH1ABB was provided by GE. Information about this PCB, its components, or  installation procedures may be found through manuals, user guides, and data sheets. The IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board product number begins with the dual-functioning IS200 series tag component coding for this IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board product's normal Mark VI Series assembly version and its domestic original manufacture location. Some of the other IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board details indicated through this medium include its:

  • DTAI functional product acronym
  • Group one Mark VI Series grouping
  • Conformal PCB coating style
  • Three-fold product revision table

Frequently Asked Questions about IS200DTAIH1ABB

What does a conformal PCB coating include?

This IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board's conformal coating is a thin layer of chemically-applied PCB protection extended to the entire base PCB of this IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board device.

How does this IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board device mount?

This IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board product mounts on a DIN-rail assembly, given its plastic installation backplane.

Reviews For IS200DTAIH1ABB

Internal Review
(5.0)

This IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board product offering from General Electric makes use of a full possible series of three significant Mark VI Series product revisions. Both a female port and a terminal strip have been made available to the highly-connected normal Mark VI Series assembly of this IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board device. This IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board product is available here with both replacement and repair opportunities. - AX Control Lead Technician
