The IS215ACLEH1AC Application Control Layer Module was manufactured by GE Industrial Systems as a component in the Innovation Series of turbine control system products, and is modified through its special assembly version and two functional revisions.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a IS215ACLEH1AC to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS215ACLEH1AC
  • SKU: IS215ACLEH1ACGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: EX2100 & EX2100e Excitation Control

IS215ACLEH1AC Technical Specifications

Manufacturer GE Industrial Systems
Series Innovation Series
Part Number IS215ACLEH1AC
Functional Acronym ACLE
Functional Description Application Control Layer Module
PCB Coating Conformal Coating
Functional Revision 1 A
Functional Revision 2 C

About the IS215ACLEH1AC

This IS215ACLEH1AC General Electric Printed Circuit Board was manufactured by GE Industrial Systems for use in their specialized Innovation Series. With this being true, the IS215ACLEH1AC PCB gains its attribution as a General Electric PCB due to GE Industrial Systems' status as a subsidiary manufacturing company of greater industry giant General Electric. This printed circuit board or PCB is better-definable by its original designated functional description as an Application Control Layer Module, as it is described as in original instructional manual materials surrounding the product. This ACLE module is actually a revised version of a different GE Industrial Systems component circuit board; modifying the  IS215ACLEH1 module through its presence of two crucial functional revisions, rated at A and C respectively.

Hardware Tips and Specifications

Unlike many other similarly-appearing GE Industrial Systems Innovation Series modules, this IS215ACLEH1AC model PCB has an elevated level of product-specific instructional manual materials that provide the prospective buyer with insight into its configuration. This IS215ACLEH1AC board has intended functionality within the Innovation Series drive assembly as a communicator across any applicable Ethernet or ISbus communication networks as needed. It should be noted that this  IS215ACLEH1AC board is dually-applicable to GE Industrial System's EX2100 Series of exciter control system products, as well.

In both the EX2100 Series Assembly as well as the Innovation Series assembly, this IS215ACLEH1AC Module is considered a dual-slot board; taking up two half-slots in each applicable board rack, as indicated by the product's unique IS215 series alignment tag. Other crucial hardware components mentionable for this  IS215ACLEH1AC board include its three visible ports; two communication ports and a singular ethernet ports. As with any hardware element included in the GE printed circuit board's board configuration, these ports have been intuitively labeled, with nomenclatures of COM1, COM2, and ENET respectively. Twelve total diagnostic LED indicators are included in this ACLE-abbreviated module's assembly; eight of which are grouped together as "STATUS"-labeled LEDs. The remaining LEDs incorporated into this IS215ACLEH1AC board's faceplate are individually-labeled, including:

  • The "OK" LED
  • The "ACTIVE" LED
  • The "ENET" LED
  • The "FLASH" LED

To configure or upgrade your IS215ACLEH1AC Application Control Layer Module after purchase, usage of the standard GE Control Systems Toolbox is required. The information on this page concerning this ACLE-abbreviated PCB is truly reminiscent of its unrevised parent PCB, as originally-developed instructional manual materials tend to focus on unrevised versions.

Frequently Asked Questions about IS215ACLEH1AC

What does this IS215ACLEH1AC board's IS215 special assembly entail exactly?

While the true correct meaning of this IS215ACLEH1AC board's special assembly version has been lost; similarly-labeled mdoels in the Innovation Series make use of SCOM grounding output terminals.

Are this IS215ACLEH1AC PCB's two functional revisions backwards-compatible?

Yes. This board features a secondary functional revision rated one letter grade above the primary functional revision; ensuring backwards compatibility.

Can AX Control repair my IS215ACLEH1AC PCB?

Yes. Here at AX Control, we are happy to offer the IS215ACLEH1AC Application Control Layer Module for both repair and replacement, with a standard one to two week lead time on most repairs.

Reviews For IS215ACLEH1AC

Internal Review
(5.0)

A component in General Electric or GE Industrial Systems' Innovation Series; this versatile IS215ACLEH1AC Application Control Layer Module is also known for its intended applications in EX2100 excitation control systems Series. In addition to the versatility shown by this ACLE-abbreviated printed circuit board, it should be considered a generally well-supported model PCB; offering an IS215-designated special assembly version and two backwards-compatible functional revisions. This IS215ACLEH1AC Application Control Layer Module is available for both repairs and replacement right here through AX Control, with a standard one to two week lead time on most repairs. - AX Control Lead Technician
