IS200EXMDG1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
The IS200EXMDG1A is part of the EX2100 series produced by General Electric, this board is an MD feedback board and has several connectors mounted to the surface. One set of the connectors is two Augat connectors, one which is three-by-three and the other which is two-by-three.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a IS200EXMDG1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200EXMDG1A
  • SKU: IS200EXMDG1AGBTC
  • Manufacturer: GE Industrial Systems
  • Series: EX2100 Excitation Control

IS200EXMDG1A Technical Specifications

Alphanumeric Catalog Number IS200EXMDG1A
Board Description Exciter MD Feedback Board
Functional Acronym/Abbreviation EXMD
Manufacturer GE Industrial Systems, General Electric Company US
Number of Augat Connectors Two
Number of Metal Oxide Varistors Two
Series EX2100 Excitation Controller

About the IS200EXMDG1A

Exciter MD Feedback Board IS200EXMDG1A is the first of two EXDM boards produced by General Electric Industrial Systems for the EX2100 series of models. This model is generally small in appearance and has several components on the board which include two metal oxide varistors (MOVs), a relay, and one resistor. Every board component on the IS200EXMDG1A model has a reference designator that is printed on the surface of the board.

There are a set of connectors on the board known as Augat connectors, these connectors are three-by-three and two-by-three. There are also two vertical pin connectors, which are varying sizes as well as a connector that is right-angled, there are also two female connection points and two male pins.

The IS200EXMDG1A is mostly obsolete at this time due to it no longer being manufactured by General Electric. If any help is needed involving help on location or wiring this board please refer to the attached GEH-6632 manual under the manuals tab on this page. Despite this model being mostly obsolete AX Control Inc can help find a replacement model for you as well as help you repair the model if needed.

Reviews For IS200EXMDG1A

Internal Review
(4.0)

The IS200EXMDG1A model is the first of the EXMD models and is mostly obsolete, due to its obsolescence it will be hard to find a replacement for this model and thus will need to be repaired immediately if damage has been obtained. - AX Control Technician

Repair Services For IS200EXMDG1A

Type Lead Time Price Action
Repair Service 1-2 weeks $1449

Our highly skilled technicians can repair your IS200EXMDG1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
