The Exciter High-Speed Relay Driver IS200EXHSG3A is typically used with a high-speed contactor for protection with high current applications. There are eight different position-plug connectors ranging from two-position up to twelve-position.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a IS200EXHSG3A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200EXHSG3A
  • SKU: IS200EXHSG3AGBTC
  • Manufacturer: GE Industrial Systems
  • Series: EX2100 Excitation Control

IS200EXHSG3A Technical Specifications

Alphanumeric Catalog Number IS200EXHSG3A
Board Description Static Exciter High-Speed Relay Terminal Board
Functional Acronym/Abbreviation EXHS
Group Variation G3
Number of Ribbon Connectors Three
Number of Twelve-Position Plug Connectors One

Product Description

Static Exciter High-Speed Relay Driver Terminal Board IS200EXHSG3A is part of General Electric’s EX2100 series. This board is typically used with a high-speed contactor for protection in conjunction with high-current applications. This board also has a built-in solid-state relay driver. The IS200EXHSG3A is the third version of the EXHS terminal boards and can be used with higher redundancy applications.

The IS200EXHSG3A board has several plug-position connectors. The different positions range from two-position to twelve-position connectors. There are three male ribbon connectors and two conduction sensors on this board as well. The board has several other components on it; the board has transistors, metal film resistors, capacitors, carbon composite resistors, and integrated circuits. There are also seven relays, these relays are all individually marked and will end in either C, M1, or M2.

The IS200EXHSG3A model is mostly obsolete at this time but can still be found either new or used. AX Control Inc offers repair services for this model, for information on repair times and costs feel free to contact us during our Monday through Friday business hours by phone at (919) 372-8413 or by email at sales@axcontrol.com

Frequently Asked Questions about IS200EXHSG3A

What redundancy type does the IS200EXHSG3A model operate in?

The IS200EXHSG3A model operates in redundant mode.

What relay does the IS200EXHSG3A model use?

The IS200EXHSG3A model uses both trip and close relays. This model is the first of the EXHS models to do so.

Can the EXHSG3 model initiate de-excitation functions?

No. For any de-excitation functions to be initiated the EMIO board attached must initiate these functions.

What field circuits does the EXHS model control?

There are two field circuits that can be controlled, the contactor and the main breaker. The field circuit that is controlled by the EXHSG3 model is the breaker field circuit.

Reviews For IS200EXHSG3A

Internal Review
(4.0)

The IS200EXHSG3A is the third of the EXHS models, this model is used with high-current models to allow for greater control. If your board obtains damage it will need to be repaired or replaced quickly. - AX Control Tech Team
