IS200ESYSH1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
General Electric EX2100e System Interface Board IS200ESYSH1A is used with generator voltage PTs and CTS needed for protection functions. The IS200ESYSH1A accepts customer I/Os and puts out transducers.

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a IS200ESYSH1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200ESYSH1A
  • SKU: IS200ESYSH1AGBTC
  • Manufacturer: GE Industrial Systems
  • Series: EX2100 & EX2100e Excitation Control

IS200ESYSH1A

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
General Electric EX2100e System Interface Board IS200ESYSH1A is used with generator voltage PTs and CTS needed for protection functions. The IS200ESYSH1A accepts customer I/Os and puts out transducers.

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a IS200ESYSH1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200ESYSH1A
  • SKU: IS200ESYSH1AGBTC
  • Manufacturer: GE Industrial Systems
  • Series: EX2100 & EX2100e Excitation Control

IS200ESYSH1A Technical Specifications

Board Description EX2100e System Interface Board for Customer I/O
Connections PTs and CTs
Functional Abbreviation ESYS from GE Industrial Systems
Manual GEA-S130A EX2100e Excitation Control Product Description
Number of sub-D pin Connectors Six

Product Description

The IS200ESYSH1A model is part of the EX2100e Excitation Controller Series of Models produced by General Electric Industrial Systems. The functional acronym for this model is ESYS which stands for EX2100e System Interface Board for Customer I/O.

The IS200ESYSH1A is designed to handle all necessary input and output interfacing. This includes PT and CT inputs, general-purpose and trip relay outputs, analog inputs and outputs, as well as digital control inputs. These interfaces occur through terminal boards mounted on the ESYS board via their terminal strips, which offer terminal connections. These daughter boards are typically HSSL or HSLA boards.

The IS200ESYSH1A board itself has isolation transformers that take care of current measurements and generator voltage. The board can take care of two three-phase PT voltage inputs and two CT inputs. It can also manage analog inputs (4 to 20 mA or +/- 10 V.). Additionally, the board supports excitation contact I/Os and has two trip relay outputs that will drive a customer lockout device.

For more information regarding the IS200ESYSH1A and its uses, please refer to the documentation provided on our site like GEA-S1310A EX2100e Excitation Control 35 A and 120 A Regulator Systems User’s Guide. On page eight there is an EX2100e Regulator Dual Control System Block Diagram that details what the External IS200ESYSH1A model is connected to how and it functions.

Here at AX Control Inc., the IS200ESYSH1A model is offered in new and used surplus. If you would like a quote regarding prices on new, used, and refurbished models, please contact us by phone at (919) 372-8413 or by email at sales@axcontrol.com.  All purchases automatically come with a warranty upon purchase. Please visit our Warranty page for additional information about specific warranty terms and conditions.

Reviews For IS200ESYSH1A
Internal Review

A certified or experienced professional is necessary for the installation or operation of the IS200ESYSH1A board. Dropping the board or incorrect power supply connections will likely result in an equipment malfunction. - AX Control Inc. Tech
