Exciter Regulator Backplane Module IS200ERBPG1A is one of the backplane boards within the EX2100 series and can be used with the Mark VI series from GE as well. The power connectors of the board are at the bottom, they are labeled TB1 and TB2, the negative power will be connected to TB2 and the positive power will be connected to the TB1. In the top corner of the board, there are five connectors; one of them is a keypad connector, three are three-position female plug connectors, and the fifth is a twelve-position female plug connector.
The IS200ERBPG1A can also be integrated to connect with stand-alone retrofitted applications, these applications should have Ethernet Modbus or serial communication protocols built in. The ERBP board provides connectivity to a number of different EX2100 boards such as the EPSM and DSPX modules.
When using IS200ERBPG1A you can find information about configuration and where to mount this board in the GEI-100488 manual. The IS200ERBPG1A now has low market availability due to obsolescence but can still be found. If interested in purchasing this board you can contact AX Control’s sales team by phone number at (919) 372-8413 for a quote.
