The IS200EHFCH1A model is from the EX2100 Excitation Controller series made by General Electric, this model is a circuit board that has three jumpers. This model also functions as an exciter fan control board. Two of the three jumpers are two-position switches, while the third is a three-position switch.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a IS200EHFCH1A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS200EHFCH1A
  • SKU: IS200EHFCH1AGBTC
  • Manufacturer: GE Industrial Systems
  • Series: EX2100 Excitation Control

IS200EHFCH1A Technical Specifications

Alphanumeric Catalog Number IS200EHFCH1A
Board Description Exciter Fan Control
Functional Acronym/Abbreviation EHCF
Group Variation H, Conformal Coating
Hardware Form H1A
Manufacturer General Electric Company USA, GE Industrial Systems
Series EX2100, Innovation Series
Weight < 1 pound

Product Description

The IS200EHFCH1A model is an exciter fan control from the EX2100 series. This board is made up of very few components as it is so small. There are three jumper switches on this small board which are labeled as J1, J2, and J3. Two of the jumpers on the board are two-position jumpers, those jumpers are J2 and J3; the J1 jumper is a three-position jumper.

On the bottom left side of the IS200EHFCH1A board, there are two LED lights that are labeled STAT and FLT. Directly next to the two LEDs there are four test points which are labeled, TP1, TP2, TP3, and TP4. The jumpers and LEDs on this small board can be replaced by AX Control’s team of specialists.

If you have any questions regarding the IS200EHFCH1A board you can contact AX Control by phone number at (919) 372-8413 so we can allow someone from our team of specialists to find ways to best help you. While this part is mostly obsolete now there are still some versions of this exciter fan control board on the market, AX Control does our best to find these parts for you.

Reviews For IS200EHFCH1A

Internal Review
(4.0)

The IS200EHFCH1A part is mostly obsolete now, but AX Control will do its best to find a replacement for you. If your model needs repairs our team of specialists is well-equipped to repair your model to make it fully functional again. - AX Control Technician

Repair Services For IS200EHFCH1A

Type Lead Time Price Action
Repair Service 1-2 weeks $870

Our highly skilled technicians can repair your IS200EHFCH1A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
