The F31X305NTBAPG1 DC300 Terminal Board

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a F31X305NTBAPG1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: F31X305NTBAPG1
  • SKU: GBTC-14417
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

F31X305NTBAPG1 Technical Specifications

Manufacturer General Electric
Series 531x Boards
Functional Part Number F31X305NTBAPG1
Functional Description F31X305NTBAPG1 DC300 Terminal Board
Series Grouping Group 1
PCB Protection Normal Coating
Functional Product Acronym NTBA
Terminal Strips 3
Terminal Pin Connections 4

About the F31X305NTBAPG1

The F31X305NTBAPG1 functions as a Three TB Card. The board has:

  • two lines of three terminal strips
  • individually numbered screw mounts
  • numbers alternating between the front and rear terminal strips
    • all even mounts on the front strip
    • all odd mounts on the rear
  • four 24-position terminal strips
  • two three-position terminal strips
Additional Relevant Hardware Components

The F31X305NTBAPG1 communicates with off-board components and other boards through its two male vertical pin cable connectors and its one female 37-pin cable connector.  It also uses its two-pin, five-pin, and nine-pin header connectors. The board also has four single terminal pin components; these are located between the terminal strips. Other components on the F31X305NTBAPG1 include:

  • seven relays
  • six resistor network arrays
  • two inductor coils
  • five potentiometers
  • sixteen jumper switches
  • transistors
  • a switch component with seven toggles
  • a rectifier diode
  • metal film resistors
  • polyester vinyl capacitors

Publications from the original equipment manufacturer, like data sheets, user guides, or manuals, will help provide information about the installation and the operation of the board.
