The F31X300CCHAFG1 is a GE CONTROL BOARD FR01/0

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a F31X300CCHAFG1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: F31X300CCHAFG1
  • SKU: F31X300CCHAFG1GBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

Product Description

The F31X300CCHAFG1 is a PCB board component manufactured by GE for use within a number of general purpose drive systems designed for industrial applications.  This includes the DC-300 drive. The F31X300CCHAFG1 board is part of the 531x series. Your system’s manual or user guide should help you establish compatibility with this series of boards.

The  F300CCH1X3AFG1 is a Control Card.  It is factory drilled for mounting in each board corner and also has other factory-made drill holes along the edges of the board.  It is marked with the alternate board number 531X300CCHABMS. It also is etched with codes like 005/0, 004/0, 94V/0 and FR01/0. Board components are marked with reference designators.

The  F31X300CCHAFG1 has six red LED indicators.  These are labeled 1, 2, 4, 8, 16, and 32. The indicators are in a single line.   The board has six vertical pin cable connectors and two header connectors. It also has multiple single-pin components.  It uses surface wiring in two locations. The board is populated with metal film resistors and capacitors made from ceramic, electrolytic, and polyester vinyl materials.

The  F31X300CCHAFG1 has a single plunge switch component.  It has over twenty resistor network arrays, eight potentiometers, and a voltage regulator.  The board has several transistors, over thirty jumper switches, and various integrated circuits, including oscillating chips and high-performance operational amplifiers.    The board has eight standoffs attached to its surface to accept and support optional auxiliary boards. Please refer to manuals or datasheets from the original manufacturer for more information, including installation procedures.
