531X305NTBANG1

5.00 (6)
Click a star to rate this product

5.00 (6)
Click a star to rate this product

531X305NTBANG1 General Electric Terminal Board 5010 ACDC 2003

Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 531X305NTBANG1 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 531X305NTBANG1
SKU: GBTC-14323

Manufacturer: GE Boards & Turbine Control
Series: 531x Boards

Description
Repairs
Warranty
Manuals

531X305NTBANG1 Technical Specifications

Manufacturer	General Electric
Series	531x Series
Part Number	531X305NTBANG1
Weight	1 lb
Regulated Power Supplies	5 VDC and 15 VDC
Unregulated Power Supplies	24 VDC or 125 VAC

About the 531X305NTBANG1

The 531X305NTBANG1 is an NTB/3TB terminal board manufactured by General Electric.
It belongs to the 531X series of replacement drive and exciter boards.
This board provides a range of interfacing system features, including relay and serial outputs, analog I/O, power supplies, and encoders.

Functional Capabilities

When installed, it can produce both regulated and unregulated power supplies:
- Regulated supplies: 5 VDC and 15 VDC.
- Unregulated supplies: 24 VDC or 125 VAC.
Encoders rated at 5 V and 15 V can be configured using onboard jumpers.
Includes seven relay outputs (Form A or Form C outputs).
- Contacts within each relay are rated at 120 VAC.
Low-level analog I/O can be scaled using the four onboard potentiometers.

Installation & Support

Installation parameters are included with the board; reviewing them is crucial to reduce the risk of damage.
When shipped from AX Control, the card is wrapped in a protective static-reducing plastic bag.
Refer to the device’s manual and datasheet for a complete wiring guide during installation.
General Electric was the original technical support provider for this terminal board.
Contact AX Control's sales staff for pricing and availability of the 531X305NTBANG1 board, as well as other parts or repairs.
