The 531X302DCIAAG5 is a DC Instrumentation Card

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a 531X302DCIAAG5 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 531X302DCIAAG5
  • SKU: 531X302DCIAAG5GBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

About the 531X302DCIAAG5

531X302DCIAAG5--DC Instrumentation Card

The 531X302DCIAAG5 is a PCB board component manufactured by GE as part of their general purpose drive systems like the DC-300 drive and other similar drives.  Many of these drives are now considered obsolete. However, they were originally created with a solid, dynamic design with the flexibility to be used in a wide variety of industrial settings and for a variety of tasks.

The 531X302DCIAAG5 functions as a DC Instrumentation Card.  It is a rectangular card with mounting holes drilled in each corner.  The board is component-dense, with six vertical pin header connectors ranging from 2-pin to 9-pin, two vertical pin male cable connectors, and a number of stab-on connectors.  The board has eight fuses. Five are located in the upper right corner of the board.

Other components on the 531X302DCIAAG5 include four heat sinks, over fifteen resistor network arrays, and a potentiometer.  The board uses a wide variety of resistors, capacitors, and diodes made of various materials and of different sizes.

The board has several transistors and jumper switches.  It has a red LED indicator and several clear light components.  The board has a large inductor coil, three transistors, a relay, and a switch component that has four individual toggles on its surface.  There are over a dozen integrated circuits on the board surface that all carry their manufacturer part numbers for easy identification. More information on the board and its operation can be found by using publications released by GE such as series user guides or drive manuals. GE initially provided technical support for this board.

AX Control is located outside of Raleigh, North Carolina.  Our team is happy to quote shipping on any purchase to your location.  Several expedited shipping options are available through our carriers.

Repair Services For 531X302DCIAAG5

Type Lead Time Price Action
Repair Service 1-2 weeks $723

Our highly skilled technicians can repair your 531X302DCIAAG5. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
