The 531X300CCHATM3 is a CONTROL CARD GENERAL ELECTRIC

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a 531X300CCHATM3 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 531X300CCHATM3
  • SKU: 531X300CCHATM3GBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

531X300CCHATM3

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The 531X300CCHATM3 is a CONTROL CARD GENERAL ELECTRIC

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a 531X300CCHATM3 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 531X300CCHATM3
  • SKU: 531X300CCHATM3GBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

Product Description

The 531X300CCHATM3 is a printed circuit board made by the General Electric company to function within several general purpose drive systems designed for industrial use.  Among these is the DC-300 drive system. The 531X300CCHATM3 has an alternate board number of F31X300CCHAFG1.

The 531X300CCHATM3 functions with these various systems as a Control Card.  The board is drilled eight times, once in each corner and once along each edge.   It is etched with its use (Control Card) and identification numbers, as well as with codes VA-4, FR00/0, 002/0, 005/0, 003/0 and 004/0.   Components are marked with reference designators for easy identification.

The 531X300CCHATM3 is built with six LED indicators.  These light emitting diodes are red in color and are numbered in sequence (1/2/4/8/16/32.)  There are eight major connectors on the board, including two header connectors and six vertical pin (male) cable connectors.   The board also makes use of several terminal pins.

The 531X300CCHATM3 board has surface wiring in several locations.  It uses primarily metal film resistors and ceramic capacitors, although some capacitors are made from polyester vinyl or an electrolytic material.

The 531X300CCHATM3 has a push button switch located in the bottom left quadrant.  The board has eight potentiometers, twenty-four resistor network arrays, eleven transistors, over a dozen jumper switches, and multiple integrated circuits.  The board has eight standoffs to allow for the addition of two auxiliary boards. Installation procedures may be found through data sheets or series manuals. Please follow all safety procedures.  Technical support for this series of boards was originally provided by General Electric.



Repair Services For 531X300CCHATM3

Type Lead Time Price Action
Repair Service 1-2 weeks $331

Our highly skilled technicians can repair your 531X300CCHATM3. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
