The 531X300CCHAFM5 is a Drive System Control Card

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a 531X300CCHAFM5 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 531X300CCHAFM5
  • SKU: 531X300CCHAFM5GBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

531X300CCHAFM5

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
The 531X300CCHAFM5 is a Drive System Control Card

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a 531X300CCHAFM5 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 531X300CCHAFM5
  • SKU: 531X300CCHAFM5GBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: 531x Boards

Product Description

The 531X300CCHAFM5 is a PCB component manufactured by GE for the DC-300 drive and other GE general purpose drive systems.   GE general purpose drives are powerful, flexible, easy to use systems that, depending on their size, are typically suited for light or heavy industrial applications.  Please review your system’s user guide or manual for compatibility with the 531x series of boards.

The 531X300CCHAFM5 functions as a Drive System Control Card.  The board is factory-drilled at each corner to allow for mounting.  It is also fitted with several stand-offs to allow for the installation of optional auxiliary boards. Cards are screw mounted to the board through the top of these standoffs.  Communication from the auxiliary to the motherboard is achieved via vertical pin (male) connectors located on the surface of the CCHA board. The board is marked with codes F31X300CCHALG2, 006/03, 002/02 and CCi-0 9407.

The 531X300CCHAFM5 is populated by six LED indicators.  These are placed in a single line in the top left quadrant of the board.  There are several examples of surface wiring used on this board, typically near the bottom of the board.

Components that appear on the 531X300CCHAFM5 include potentiometers, resistor network arrays, voltage regulators, transistors, and TP test points.  The board also has two switch components. There are 28 jumper switches on the board surface, along with six vertical pin cable connectors and two header connectors.  The board is populated by resistors, capacitors, and diodes. There are over thirty integrated circuits of various design on the board surface. User guides and manuals from the manufacturer will provide more information.

Repair Services For 531X300CCHAFM5

Type Lead Time Price Action
Repair Service 1-2 weeks $369

Our highly skilled technicians can repair your 531X300CCHAFM5. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
