Product Description

531X199SPTADG1--Communication Pulse Transformer Board

The 531X199SPTADG1 is a board component fabricated by General Electric to fit into their general purpose drive systems like the DC-300 drive.

The 531X199SPTADG1 is a Communication Pulse Transformer Board.  It is a long, rectangular board that has only a few components on its surface.  It is drilled in each corner for mounting and has several other drill holes. It is marked with codes like 002/1, FR01/0,  0390, VA-4, and its alternate board number of F31x199SPTABG1. The center of the board includes a graph relating to the board jumpers.   The board has three jumpers.

The 531X199SPTADG1 has six transformers placed in a single line along the top edge of the board.  These are placed on the board as three/one/two transformers. Each transformer has a two-pin header connector, a ceramic capacitor, and three resistors (two metal film and one CCR) related to it.   There are four stab-on connectors located between the single transformer and the set of two transformers.

Other components on the  531X199SPTADG1 include six additional stab-on connectors located on the left edge, next to a field of carbon composite resistors.  There are twelve CCRs in this field. There is also a field of twelve metal film resistors. These two fields are separated by the three previously mentioned jumpers.   There are two male vertical pin cable connectors on the right edge of the board, along with more metal film resistors, ceramic capacitors, a single integrated circuit, one terminal pin that is marked +24V, and one high-voltage capacitor.   More information on this board may be accessed through data sheets, manuals, or user guides.
